Help Center130HP Dongfeng Aerial Ladder Trucks,truck Mounted Boom Lift
Related Products
-
JAC High-altitude Work Vehicle,aerial PlatformUS$ 22,200 - 27,495MOQ: 1 Unit -
JMC Aerial Platform Vehicle,high-altitude Operation CarUS$ 22,200 - 27,495MOQ: 1 Unit
-
Boom Boist Truck,rear Lift TruckUS$ 22,486 - 27,495MOQ: 1 Unit
-
Elevated Working Platform Truck,safety Aerial Truck,high-altitude Operation TruckUS$ 16,875 - 18,657MOQ: 1 Unit
-
High-altitude Work Vehicle,aerial Work PlatformUS$ 16,875 - 18,657MOQ: 1 Unit
Cherry picker,high-altitude operation truck,hydraulic aerial cage
Lifting Platform Truck(truck mounted boomlift, hydraulic lifter)Platform lift truck for sale, hydraulic lift truck service.If you are searching for the best lifter machine,chengli is your best choice.We provide high quality lift platform truck with the wheel base of dongfeng, faw, cnhtc,etc.Our platform lifter truck prove handy in many applications also.Platform lift truck is wildly use in municipal work,garden work, electrical maintenece.Also as a warehouse of platform lifter, we supply any paltform lift truck part, hydraulic lifter machine,hydraulic platform
1.working height can be 10m,12 m ,14 m,16m,18m,20m,22m,...2 booms ,3 booms ,4 booms for choosing
2..4*2 ,6*2,6*4 ,8*4
3.Cummins ,SD(sida),CY engines
4.Euro 2,Euro 3,EGR, Euro 4
5.Dongfeng ,Foton,Foton auman ,howo , ,JAC,FAW,Shacman,Steyr chassis for choosing
quick for Man-lift Truck
| Item | unit | parameter |
| Chassis model | NKR77-- | |
| Overall dimensions | mm | 6800×1940×3020 |
| GVW | kg | Appro×8200 |
| Mass in working order | Appro×4770 | |
| Wheel base | 3360 | |
| F/R track base | 1015/2155 | |
| Lift height | m | 15m |
| Exhaust/hp | ml/kw | 2999/130 |
| Max speed | km/h | 90 |
| Tire specification | 7.50-15 | |
| Traction system | 4×2 | |
| Number of axles | 2 | |
| Engine type | - | 4KH1-TC |
| transmission | - | 6-speed with over drive |
| Electric system | v | 24v |
| Operation control system | Electrically hydraulic control | |
| Allowable passengers in cab | pcs | 2,3 |
Lift Specification
| specification | SQ3.2SK1Q/SQ3.2SK2Q | unit |
| Max Lifting Capacity | 3200 | kg |
| Max Lifting Moment | 6.72 | T.M |
| Recommend Power | 14 | kw |
| Max Oil Flow of Hydraulic System | 25 | L/min |
| Max Pressure of Hydraulic System | 20 | MPa |
| Oil Tank Capacity | 30 | L |
| Rotation Angle | All Rotation | |
| Crane Weight | 1172/1316 | kg |
| Installation Space | 850 | mm |
1.standard configuration
2.boom streaching :1100 mm ( boom can be lengthern upon your request )
3. work basket can have insulation if you need ; commutating-pole machine for choose
Cherry picker out-look
Company brief
HuBei ChengLi Special Automobile Co., LTD is a manufacturing group located in SuiZhou City, HuBei Province,China. SuiZhou is near to wuhan, Xiangfan and Shiyan,with these cities, there is a Golden Car Manufacturing hallway along the 318 highway. Among that, SuiZhou is famous as the capital of Chinese special automobile manufactory
Since being founded in 1998, ChengLi has continually worked to improve its production processes and production tools. Qualified personnel ensure the highest standards of quality control in the manufacture of the principal components and the final assembly. Covering an area of 8 hectares more than 5000 vehicles are produced each year. Our company has independent export right, the product had delivery to many countries around the word. Take 2008 for example, the amount of export reach 2000 units. The registered Labels CLW is well known in these years.
Based on high quality and advanced technology, the leading varieties include more than 200 types of trucks such as water truck, garbage truck, fecal and sewage suction truck,refuse compactor, fuel tank, aerial platform, truck with crane, dump truck, van truck, trailers, fire-fighting truck, refrigerator truck, tractor, bulk cement truck, chemical liquid truck, concrete mixer truck, LPG tank, etc. All products have passed the ISO9001-2000 and t 3C(China Compulsory Certification) standard.
Photoes for work shop
Company certification
ompany pass the 3 c certification, BV certification, iso9000 quality system certification, environmental quality certification, SGS certification, and products.At the same time the company has also issued by the national government contract and credit enterprise certification, as well as issued by the bank credit enterprise, credit enterprise and user vote through the network.
---factory cetification
-- products certification
More questiones
No.1 Payment
We only Accept T/T or Western Union;(30%as deposite, after Inspectiing at our factory ,pay the blance 70%) If you don't accepet, We sincerely welcome you to our factory for inspecting or discussing
No.2 Packing
Nude, Covered with max, small type can be put into 20"GP,or 40GP,40HQ,big type can be carried by bulk ship or RO-ROshipping or according to your requirement
No.3.Delivery Time
We have lots of truck in stock, delivery time is 7-15days as long
Remarks :
The above Infomation is just for your reference.We can manufacure the truck as eachyour request.
Any questiones, pls feel free to reach me ,It would be great pleasure to be on your service.
Pls scan two-dimensional code and welcome to reach Ada by Tel 0086-13545361399
