16m Dongfeng hydraulic aerial working truck for sale
High Altitude Operation Truck, mainly means the truck that could lift up and down the platform to operate by several hydraulic cylinder supported with the hydraulic system or electric system above the height of 3 meters.
The high operation truck with people loading is one of the advanced mechanic equipments. The worker work at some certain height with the help of the high altitude operation truck in proper condition and then it should be safe.
1.Technical Specification
Item | Unit | Specification | |
Product name |
| CLW5040JGKZ3 high-altitude truck | |
Chassis model |
| EQ1042NJ20D3 | |
| Gross weight | kg | 4325 |
Curb weight | 4000 | ||
Overall dimension | mm | 7400×1980×31100 | |
wheelbase | 3300 | ||
Approach/departure angle | ° | 19/11 | |
Engine model |
| CY4102-C3F | |
Engine manufacturer |
| Dongfeng Chaoyang Diesel Co.,Ltd | |
Transmission |
| 5 gears | |
Emission standard |
| Euro III | |
Displacement / Power | ml/kw | 3856/70 | |
Tire specification / Number | pcs | 7.00-16/6 | |
Max speed | km/h | 90 | |
Max working height | m | 16 | |
Rated platform load | kg | 200 | |
Rated manned platform | man | 2 | |
Slewing angle(Left,Right) | ° | 360 | |
Outrigger type / Q’ty | pcs | H-type, 4 pcs | |
Remark | The whole truck is operated through upper and lower hydraulic operation, equipped with hook. | ||
Packaging
(1) About the package of our trucks,usually it is nude that covered with wax. And it also can be packed as your need.
(2) About the shipping,there are many ways, such as Ro-Ro Ship / Bulk transport / Container packing / SKD / etc. And it can be offered according to your request.
Notes:
A. Delivery time: Normally with 20-25 days after received your first deposit.
B. Payment item: Normally 30% in advance and the balance should be paid before the shipment after your checking and confirmed.
C. Guarantee time and services: from the vehicles safely arrived at destination and under proper operation situation, normally 12 months, but the whole life supply maintenance
