DONGFENG KINGRUN 4*2 Tipper Garbage Truck 15m3
Tipper Garbage truck is also called garbage collecting truck, garbage transport truck, mainly used in transporting kinds of garbage for municipal sanitatio ,large factories and mines ,etc, especially apply to transport household waste in residential area. According to loading and unloading type, it is divided into the following categories: dump garbage truck, hook arm garbage truck, compactor garbage truck, swing arm garbage truck, self-loading garbage truck, sealed type garbage truck.
Product Note:
1. This type belongs to tipper garbage truck, mainly used in garbage compression station
2. Adopt Dongfeng New Kingrun 4*2 chassis, equipped with 190hp engine;
3 Dustbin operation is controlled by hydraulic cylinder, easy and convenient.
Main Parameter of DONGFENG KINGRUN 4*2 Tipper Garbage Truck 15m3
Main Technical Parameter | |||
Product Name | DONGFENG Tipper Garbage Truck | Overall Dimension(L*W*H)(mm) | 7800×2500×3200 |
Gross Weight(kg) | Approx 12495 | Approach/ departure angle (° ) | 34/15 |
Curb weight(kg) | 7300 | Dustbin volume(m3) | 15 |
Axle number | 2 | Front/Rear axle load(Kg) | 4115/8380 |
Cab capacity | 3 | Front/ rear suspension(mm) | 1450/2150 |
Wheelbase(mm) | 4200 | Front/Rear tread(mm) | 1920/1860 |
Cab type | one and half row, flat proof | Max Speed (km/h) | 90 |
Chassis Technical Parameter | |||
Chassis Model: | DFL3120B1 | Chassis Manufacturer: | DONGFENG Motor Co., Ltd |
Gear box | 6 forward and 1 reverse | Transmission type: | Manual |
number of tires | 6 with a spare | Leaf Spring number: | 8/10+8 |
Tire size | 10.00-20,10.00R20 | Traction Type: | 4*2 |
Engine specification | |||
Engine Model: | B190 33 | Engine Brand | DONGFENG |
Emission stand | Euro 3 | Displacement(ml) | 5900 |
Fuel type: | diesel | Power(kw) | 140(190hp) |
Warranty | 12 months, from the date of supply | ||
Remark | 1. 24V Electric system, electrically hydraulic operation control | ||
2. Equipped with docking dustbin, unloading form: rear dump type | |||
3. Van material: carbon steel | |||
This Tipper Garbage Truck show as following:
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
Our Certificates:
Production Equipments:
Contact Information:
If you have any questions, pls feel free to contact with me via e-mail or phone, I will try my best to help you. You can count on me. Please remember as below:
