DONGFENG KINLAND 6*4 Hook Lift Refuse Truck 16m3
Hook Lift Refuse Truck is also called garbage collecting truck, garbage transport truck, mainly used in transporting kinds of garbage for municipal sanitatio ,large factories and mines ,etc, especially apply to transport household waste in residential area. this truck can be equipped with many buckets , high effiency, economical
Production notes:
1 ISO9001,3C
2 High quality, low price
3 Economical, practical
4 Easy to use ,operate conveniently
5 DONGFENG 6*4 chassis,245/260hp
,
Technical Parameter of DONGFENG KINLAND 6*4 Hook Lift Refuse Truck 16m3
Main Technical Parameter | |||
Product Name | DONGFENG Hook Lift Refuse Truck | Overall Dimension(L*W*H)(mm) | 8590×2495×3295 |
Wheelbase(mm) | 4350+1300 | Approach/ departure angle (° ) | 20/21 |
Loading capacity(m3) | 16 | Curb weight(kg) | 11300 |
Front/ rear suspension(mm) | 1460/1480 | Axle number | 3 |
Cab capacity | 3 | Max Speed (km/h) | 90 |
Chassis Technical Parameter | |||
Chassis Model: | DFL1250A8 | Chassis Manufacturer: | DONGFENG Automobile Co., Ltd |
Gear box | DONGFENG 9 shift | Transmission type: | Manual |
Brake System | air brake | Leaf Spring number: | 8/9,8/10 |
Steering type | LHD with power steering | Number of Tire | 10 with a spare |
Tire size | 11.00-20,11.00R20,295/80R22.5 | Traction Type: | 6*4 |
Engine specification | |||
Engine Model: | C245 33 | Engine Brand | DONGFENG |
Emission stand | Euro 3 | Displacement(ml) | 8300 |
Fuel type: | Diesel | Power(kw) | 180(245hp) |
Warranty | 12 months, from the date of supply | ||
other Equipment or performances | 1. 24V Electric system, electrically hydraulic operation control | ||
2. optional equipped with one or more metal bucket | |||
This Hook Lift Refuse Truck show as following:
more Hook Lift Refuse Truck show as the following:
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
Our Certificates:
Factory Show:
Production Equipments:
Trucks Exported:
1. Are you manufacturer or trading company?
We are direct manufacturer;
2. Min Order Quantity:
One unit or one sets;
3. Handling Time:
Within one day;
4. Payment Terms:
30% deposit, 70% balance before shipment by TT or Irrevocable LC at sight;
5. Specified delivery date from the Date of Order:
Depend on the detailed request and purchase order quantity.
6. Contact Information:
For any question or request, please contact with me freely according to the following information:
