DONGFENG 4*2 Skip Refuse Truck 8 m3 with Bucket
Skip Refuse Truck is also called garbage collecting truck, garbage transport truck, mainly used in transporting kinds of garbage for municipal sanitatio ,large factories and mines ,etc, especially apply to transport household waste in residential area. According to loading and unloading type, it is divided into the following categories: dump garbage truck, hook arm garbage truck, compactor garbage truck, swing arm garbage truck, self-loading garbage truck, sealed type garbage truck.
Production notes:
1 Factory direct sale
2 DONGFENG 4*2 chassis,190hp
3 Economical,practical
4 High quality,low price
5 Easy to use ,operate conveniently
Technical Parameter of DONGFENG 4*2 Skip Refuse Truck 8 m3 with Bucket
Main Technical Parameter | |||
Product Name | DONGFENG Skip Refuse Truck | Actual volume( m3 ) | 8 |
Overall Dimension(mm) | 7600×2470×3380 | Curb Weight (kg) | Approx 7110 |
Garbage bucket size (L*W*H)(mm) | 3300*1900*1500 | Wheelbase (mm) | 3800 |
F/R Suspension(mm) | 1430/2370 | Number of Axles | 2 |
Appr/Dep Angle(º) | 20/18 | Max Speed(km/h) | 90 |
Cab Allowed Persons | 3 | Cab type | Flat proof, one and half row, air conditioning |
Chassis Technical Parameter | |||
Chassis Model | DFL1140B1 | Chassis Manufacturer | DONGFENG Motor Co., Ltd |
Gear Box | 6 speed forward and 1 reverse | Transmission type | Manual |
Steering Type | LHD | Brake System | Air brake |
Leaf Spring No. | 7/9+6,8/10+8 | Number of Tires | 7 include 1 spare |
Drive Type | 4x 2 | Tire Spec. | 9.00-20 |
Engine Technical Parameter | |||
Engine Model | B190-33 | Engine Brand | DONGFENG |
Fuel Type | Diesel | Emission Standard | Euro 3 |
Displacement ( ml ) | 5900 | Power (KW) | 140(190hp) |
Superstructure Parameter |
| ||
Material of compartment | Carbon Steel | Bucket dimension(mm) | Side 3mm ,floor 4mm |
Hydraulic system pressure | 16Mpa | swing arm turn radius | Approx 6000mm |
Swing arm maximum pivot angle | 145 | Hoisting time | 30s |
Unloading time | 50s | Control type | Electric hydraulic and manual |
Warranty | 12 months, from the date of arrival the destination | ||
Truck Picture of DONGFENG 4*2 Skip Refuse Truck 8 m3 with Bucket :
1, Packaging: nude or waxing;
2. Shipping: in the container or Ro-Ro ship or bulk ship according to the customer’ order or requirement;
1. Factory direct supply: reliable quality and fast delivery;
2. Warranty; from the date of receiving, in normal use within 30000kh or within one year, we will repair for free, but the wearing parts and electrical parts are not included. After one year, we only charge cost when the question occurs;
3. Tracking service: lifelong
4. Chassis question: when the question occurs, please find the local nearest Service Station for repair or maintenance, or call us if the local have no Chassis Service Station;
5. Spare Parts: Superstructure spare parts is sent by ourselves, we only charge cost; Chassis spare parts is sent by the local Service station, if the local have no chassis service station, please call us freely.
6. OEM Ability: We can customize the truck according to your request, such as material, size, color, paint, logo, etc.
7. Warm tip: please operate, use, and maintain the truck according to our manuals and Instructions. When the question occurs, please call us freely.
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
Our Certificates:
Production Equipments:
Trucks Exported:
Contact Information:
If you have any questions, pls feel free to contact with me via e-mail or phone, I will try my
best to help you. You can count on me. Please remember as below:
