DONGFENG 4*2 Self-loading waste truck 10ton
Self-Loading waste Truck 10ton is also called garbage collecting truck, garbage transport truck, mainly used in transporting kinds of garbage for municipal sanitatio ,large factories and mines ,etc, especially apply to transport household waste in residential area. According to loading and unloading type, it is divided into the following categories: dump garbage truck, hook arm garbage truck, compactor garbage truck, swing arm garbage truck, self-loading garbage truck, sealed type garbage truck.
,
Product note:
Self-Loading waste Truck 10 ton is constructed by 4mm good quality carbon steel, the body is fitted on the chassis by the truck beam. It is widely used in garbage disposal in street , school and other places, can be equipped with many garbage bucker, it have dump function, hydraulic operation, dump conveniently.
Product features of this Self-Loading waste Truck 10ton :
1.Self-loading & self-unloading;
2..Environmentally friendly ;
4. ISO9001,3C
5. High quality low price
6. Economical ,Practical
,
Main technical parameter of DONGFENG 4*2 Self-loading waste truck 10ton
Product Model | DONGFENG Self-loading waste truck 10ton | Overall Dimension(L*W*H)(mm) | 7350×2470×2730 |
Curb weight(kg) | 6800 | Cargo box Dimension(L*W*H)(mm) | 4200×2300×1470 |
Loading capacity(m3) | 12 | Wheelbase(mm) | 3950 |
Axle number | 2 | Approach/ departure angle (° ) | 33/18 |
Cab type | Single sleeper | Cab capacity | 3 |
Steering type | LHD with power steering (optional RHD) | Max Speed (km/h) | 90 |
Chassis Technical Parameter | |||
Chassis Model: | EQ1110GLJ | Chassis Manufacturer: | DONGFENG Motor Co., Ltd |
Brake System | Air brake | Transmission type: | Manual |
Gear box | 6 shift | Number of tire | 6 with a spare |
Tire size | 9.00-20 | Traction Type: | 4*2 |
Engine specification | |||
Engine Model: | B170 33 | Engine Brand | DONGFENG |
Emission stand | Euro 3 | Displacement(ml) | 5900 |
Fuel type: | Diesel | Power(kw) | 125(170hp) |
Warranty | 12 months, from the date of supply | ||
Superstructure parameter |
| ||
Multi-faceted Picture of DONGFENG 4*2 Self-loading waste truck 10ton :
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
Our Certificates:
Production Equipments:
Trucks Exported:
Contact Information:
If you have any questions, pls feel free to contact with me via e-mail or phone, I will try my best to help you. You can count on me. Please remember as below:
