290 hp 6*4 DONGFENG Concrete Mixing Truck 8 m3
DONGFENG Concrete Mixing Truck , is also called cement truck, concrete mixing truck, cement mix truck, concrete mixing transport truck, mainly used in transporting mixed concrete used in construction with mixing drum. We can manufacture cement mixer truck from 3m3 to 16m3, Cement Mixer Truck can select DONGFENG, SHACMAN, FAW, FONTON, HOWO, etc.
Product Notes:
1. This truck adopt plow shape mixing angle, perfect carbon steel, rugged wear;
2. Feed,discharge fast speed, stir well;
3. Main component adopt imported Italy PMP equipment , high quality
4. DONGFENG 6*4 chassis, Yuchai 290hp, mixing volume: 8-10m3
5. Competitive price
Main Parameter of 290 hp 6*4 DONGFENG Concrete Mixing Truck 8 m3
Main technical parameter | |||
Product Model | DONGFENG Concrete Mixing Truck | Product Brand | DONGFENG -CLW |
Mixing Volume(m3) | 8-10 | Overall Dimension(L*W*H)(mm) | 9200×2500×3760 |
Curb weight(kg) | 11815 | Wheelbase(mm) | 3800+1350 |
Axle number | 3 | Max Speed (km/h) | 90 |
Cab type | Flat proof, single sleeper, air conditioning | Cab capacity | 3 |
Chassis Technical Parameter | |||
Chassis Model: | DFD1254 | Chassis Manufacturer: | DONGFENG Motor Co., Ltd |
Gear box | FAST 9 shift(9 forward and 1 reverse | Transmission type: | Manual |
Steering Type | RHD with hydraulic power steering | Traction Type: | 6*4 |
Brake System | Air brake, Exhaust brake, breathe brake | Leaf Spring number: | 9/10 |
Number of tire | 10 with a spare | Tire size/type | 10.00R20 (steel tire) |
Engine specification | |||
Engine Model: | YC6M290-33 | Engine Brand | GUANGXI YUCHAI |
Emission stand | Euro 3 | Displacement(ml) | 9839 |
Fuel type: | Diesel | Power(kw) | 215(290hp) |
Superstructure parameter |
| ||
2. Equipped with Italy PMPhydraulic pump, hydraulic motor, speed reducer | |||
Multi-faceted of 290 hp 6*4 DONGFENG Concrete Mixing Truck 8 m3 :
Imported Italy PMP Hydraulic Motor and Hydraulic Pump , speed reducer:
Radiator :
400 L Water Tank :
Operating lever :
Air pessure water supply :
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
