Help CenterPull Rod (chain) Tester
Related Products
-
Electronic Concentrated Controlling Pneumatic Brake Testing System (separate Testers)NegotiableMOQ: 1 Set -
Micro-controlled Automatic Brake Shoe Slack Adjuster Test BenchNegotiableMOQ: 1 Set
-
Bogie Load TesterNegotiableMOQ: 1 Set
-
Buffer Drop Impact TesterNegotiableMOQ: 1 Square Meter
-
Wheel Set Automatic TesterNegotiableMOQ: 1 Set
Specifications
Inspecting pull rods (chains) on wagon brake systemWith advantages of advanced design,perfect elements,full automatic control.
Product structural design:
1,The teststand adopts the troughing structure, with holes every other 80mm in both sides of the trough, is able to inspect all work pieces of which dimensions are between 0.5m to 10m. So the tester can not only inspect existing pieces, but also new pieces in future which are longer.
2,The contact area is made by 40Cr material and taken hardening and tempering which improves the strength of integral structure.
3,The control system is advanced PID operation panel.
4,The hydraulic system consists of integrated oil-flowing system and accurate proportional overflow valve with pressure range of 0.8Mpa-18Mpa.
5,The tester adopts close-cycle control system, high precision drawing force transducer and digital display system, which improve the control precision and avoid the errors.
Performance parameter:
Inspecting object: pull rods (chains) used in railway wagon brake system.
working principle: automatically inspecting by imitating actual drawing force.
Measurement range (drawing force): 10kN-80kN
Length of work pieces0.5-10m
Inspection precision: <0.5kN
display mode: chromatic digital display by fluorescent(digital)display tube
Performance temperature: -10~40
Electric power: three-phase four-wire system, 380V±10%, 50Hz, Power rating 4kW
The companies and sectors using our products at present:
Zhengzhou northern car depot
Shenmu northern car depot
Shenyang rolling stock company
