air screening machine for gypsum powder
Working Principle
WS series air screening machine abandons gravity working principle, adopts the working principle of kinetic energy to do works, with the air as carrier,. Mixes materials with the air under pressure, then make them to enter into the middle of wheel, spay through the screen with the enough eccentricity powder, and are collected by the snail shell. For those, which cannot through the screen, are discharged automobile through exclude to gain sieving propose.
Function characteristic
High efficiency sieving : more than 95%
The output is about 5-10 times or more than vibrating sieve
Wide scope of thinnest: powder materials with the size of 80-600 mesh can filter with high efficiency
Precision of thinnest, no super and mixture grade
Install uprightness, long duration
Siving procedure is processed under pressure, no powder pollution
Be matched with all kinds of mill and mesh work
Low noise, low consuming, continuous working, decrease maintain.
Materials
Black lead powder, resin powder, Chinese medicine powder, pigment, industrial medicine , cosmetic, fire proof plastic powder, china clay, griddle, aluminum powder, glass powder, endure fire materials, starch, milk powder, metallurgy, electricity materials, copper powder, carbon black, active carbon, light carbonate calcium iron ore.
Parameter | WS-600 | WS-1000 | WS-1600 | WS-2000 |
Airflow(m3/h) | 240 | 300 | 460 | 720 |
Screen mesh | 80-600 mesh | |||
Material size | < 40 mesh | |||
Motor power | 3 KW | 5.5 KW | 15 KW | 18.5 KW |
Rotation rate | 1450 r.m.p | 960 r.m.p | 828 r.m.p | 548 r.m.p |
Diameter(mm) | φ600 | φ1000 | φ1600 | φ2000 |
Height(mm) | 1550 | 1730 | 2400 | 2400 |
Company Information
Gaofu company is established in 1982,which specialized in vibrating machine and sieving equipment and coal crusher for 31years,with advanced manufacture equipment, abundant technology power, have the honor to get famous brand in Henan, high and new technology enterprises. our industry first passed ISO9001:2008 International Quality Management System Authentication and Germany CE certification.
Our Services
FAQ
1.How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every macchine before delivery.
2.Guaranteed:
If products’quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
3.How about price?
Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that “ for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity”.
4.Service and Payment Terms?
A. We usually accept T/T, L/C;
B. T/T: 30% in advance as down payment, the balance before delivery;
C. We take pictures of finished products before delivery.
