Gaofu vibrating screen --sieving chemical powder
- 80 Set / Sets per Month
- Tianjin/qingdao
- T/T
- Wheat flour vibrating screen machine---China first class separator
- vibrating separator for wheat flour
- GFSZS-1200 Flour Rotary Vibratory Screen Machine
- High Quality Stainless Steel Rotary Flour Sifter Machine
- high output wheat flour vibroscreen
- Direct Discharge food grade vibro flour sifter with SGS and CE
Product Details
Place of Origin: | Henan, China | Brand Name: | GAOFU | Model Number: | S49-600-1S-SUS304 |
Packaging Details
Wooden case or according to your require
Product Description
Gaofu vibrating screen --sieving chemical powder
Introduction
S49-A series vibrated filter is one of précised powder griddle,Low noise, high efficiency, need only 3-5 minutes to rapidly replace the griddle,all closed structure.Used to filter particles,powder and mucilage.
Principle of the structure
S49-A series vibrated griddle: use upright motor as the source of vibration,equippedeccentricity hammer on the both sides of the topandthebottom,changecircumrotatetolevel,uprightandslopemovement, then pass these three movement to the surface of the griddle.Adjust the phasic angleonthebothsides of the top and bottom to change the movement orbits of the surface griddle.
Features
High efficiency, refined design, duration,any powders and mucilage are suitable for using.
Easily to replace the net, simple operation and convenience washing.
Never jam the hole meshwork, no powder flying, filter size of the powder between 500 mesh and 0.028 mm.
Discharge the impurity and coarse materials automobile and operates continuously.
Unique net flame design, long duration of net, only 3-5 to replace the network.
Small volume, move easily.
The highest layers of the griddle are about 5 layers. But 3 lagers are suggested.
Scope of application
Chemical industry: resin, pigment, industrial medicine, cosmetic, coatings, Chinese medicine power.
Food industry: sugar powder, starch, salt, rice noodles, milk powder, soybean milk, egg powder, sauce, syrup.
Metal, metallurgy mining industry; aluminum powder, ceruse, copper powder, ore alloy powder, welding rod powder, dioxide manganese, electrolyse copper powder, electomagnetism materials, rubbing powder, fire-proof material, kaolin, lime, alumina, heavy calcium carbonate,quartz.
Social pollution disposed; disposed oil, disposed water, disposed dye waste water,assistant detergent, active carbon.
Technical Parameters
Model | Effective Diameter for sieving surface(mm) | Effective sieving area(m2) | Sieving mesh specification | Layers | Power(KW) | |
Vibration motor | Common motor | |||||
S49-400 | 340 | 0.0907 | 2-500 mesh | 1-5 | 0.18 |
|
S49-600 | 540 | 0.2289 | 2-500 mesh | 1-5 | 1.25- | 0.75 |
S49-800 | 730 | 0.4183 | 2-500 mesh | 1-5 | 1.55 | 1.1 |
S49-100 | 900 | 0.6359 | 2-500 mesh | 1-5 | 1.1 | 1.5 |
S49-1200 | 1100 | 0.9499 | 2-500 mesh | 1-5 | 1.1 | 1.5 |
S49-1500 | 1400 | 1.5386 | 2-500 mesh | 1-5 | 1.5 | 2.2 |
S49-1800 | 1700 | 2.2687 | 2-500 mesh | 1-5 | 4 | 3.0 |
S49-2000 | 1886 | 2.7922 | 2-500 mesh | 1-5 | 4 | 3.0 |
Spare parts
Product display
Company Profile
Xinxiang Gaofu Sieving Machinery Co., Ltd. specializes in manufacturing vibration screens and vibrating sieves. To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
Thanks to production equipment, strong technical capabilities, improved detection means and strict managing system, we have enjoyed good reputation.
our company has attained ISO9001:2000 certification and CE Certification. Our products sell well throughout China and are exported to North America, West Europe, Southeast Asia and other countries and regions.
Do you want to improve your product quality? Do you want your products to become more competitive? Choosing Xinxiang Gaofu Sieving Machine Co., Ltd.! We will be your friend in the way to success! And you will create a shiny future in 2014!
Please visit our website: www.gaoful.com.
Our tenet: "Honest Service, the Highest Quality".To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
