GAOFU New Type Mining Vibrating Hopper Feeder Machine
1. Summary description:
ZG series motor vibrator feeder is a kind of general feeding device, which tends to standardization. It is widely applicable for relevant industries to convey all kinds of block, particle and dust materials in short distance. The feeder can well implement the on-line and automatic operation with continuous conveying system like belt, automatic scaling and quantitative packing system etc. It is an ideal feeding and conveying device for the industries of metallurgy, mining, coal, construction material, chemical, power, and grain process.
ZG series motor vibrator feeder compared with electromagnetic vibrating feeder and reciprocating feeder have the advantages of compact and easy structure, durable and sturdy, continuous and homogeneous feeding, and low wear of trough, long service life, and convenient maintaining. The feeder has two structure forms, open and closed, according to the requirements of field working environment; motor could be installed on upper, lower or side face in order to form three different vibrating source installation positions.
According to the requirements of user and field operation, the feeder has several choices of joint devices such as seated or suspended installments, and allocating control valve, working table or not.
2. Motor vibrator feeder Specification:
Model |
Feed size(mm) |
Capacity (t/h) |
Motor |
Power (KW) |
Double amplitude |
Weight(KG) |
|
Close |
Open |
||||||
ZG-25 |
60 |
25 |
YZO-2.5-4 |
0.25*2 |
2-3 |
240 |
174 |
ZG-30 |
80 |
30 |
YZO-5-4 |
0.4*2 |
2-3 |
256 |
184 |
ZG-50 |
90 |
50 |
YZO-5-4 |
0.4*2 |
2-3 |
295 |
235 |
ZG-100 |
105 |
100 |
YZO-8-4 |
0.75*2 |
2-5 |
384 |
321 |
ZG-200 |
115 |
200 |
YZO-17-4 |
0.75*2 |
2-5 |
432 |
372 |
ZG-400 |
140 |
400 |
YZO-20-4 |
2.0*2 |
2-5 |
686 |
606 |
ZG-750 |
190 |
750 |
YZO-30-4 |
2.5*2 |
4-6 |
1258 |
1030 |
ZG-1000 |
215 |
1000 |
YZO-50-4 |
3.7*2 |
4-6 |
1446 |
1156 |
Note: This specification is just for reference, any changes are subject to the products.
3. Machine disply:
4. Customer visit
GAOFU company have a perfect after-sales service system and professional technology team to provide customers with prompt and thorough service. Our price are most competitive and reasonable, all order will be supplied within the stipulated period. Awaiting your first inquiry order
CE and ISO Certificate
Top after sales service
