Hyraulic Crawler Drilling Rig (CTQ-D100YA2)

Name: Hyraulic Crawler Drilling Rig (CTQ-D100YA2)
Brand: longye
SKU: 141558518
Availability: InStock

Hyraulic Crawler Drilling Rig (CTQ-D100YA2) thumbnail-1

Hyraulic Crawler Drilling Rig (CTQ-D100YA2) photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Core Drilling Rig

Place of Origin:

Shandong, China

Contact Supplier Request Quote Chat Now

Shandong Longye Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Core Drilling Rig

Place of Origin Shandong, China

Brand Name longye

Model Number CTQ-D100YA2

Usage Ore

Specifications

CTQ-D100YA2 hydraulic crawler drilling rig,low air pressure hydraulic drilling rig

CTQ-D100YA2 hydraulic crawler drilling rig

CTQ-D100YA2-type crawler hydraulic drilling rig, using a new hydraulic technology, with low air consumption rotary torque, variable-bit-shift convenient hole, the drilling rig structure, a compact, the smallest turning radius of only 2.8m, while promoting a retractable sliding shelf compensation, drilling hole when the sliding frame support on the ground, drilling and good stability.

The drilling rig is mainly suitable for open mining, water conservancy, power plants, road building and other Rock drilling blasting holes.

1,Rotary structure can be low, medium and high-speed switching, perforation of the work to meet the needs of the different rock

2,Double-pump reduces the pump using the failure rate and maintenance costs

3,Walking with high torque agencies to ensure a strong power output of

4,Enhance and promote organizations to adopt the fuel tank of the completion of reliable

Main technical parameters

Total Weight (kg)	2800
Drilling diameter (mm)	90---130
Dimension (L * W * H)	410020302020
Drilling depth (m)	30
Travelling speed (km/h)	2
Once promotion distance (mm)	2000
Grade ability (°)	30
Working pressure (Mpa)	0.7---1.0
Chassis ground clearance (mm)	250
Air consumption (m³/min)	7---10
Skid pitch (°)	up and down total 100
Host Power (Kw)	33
Sliding tilt swing (°)	Left 35, right 10
For rock (f)	6----20
Skid compensation (mm)	900
Impact frequency (r/min)	840

Note: The Company’s products continued to improve; various design and technical specifications may change at any time, without any additional notice or obligation.
