CTQ-Z138YA Hydraulic Crawler Down the Hole Drilling Equipment /Blasting Hole Drilling Rig
- QINGDAO
- T/T Money Gram
You May Like
-
CTQ-Z138YA Hydraulic Soil Nailing /slope Protect Drilling Rig
-
CTQ-Z138YA Hydraulic Soil Nailing /slope Protect Drilling Rig /blasting Hole Drilling Rig
-
60m Deep G40YF Large-size Engineering Construction Machinery on Sale
-
Longye Diesel Power Down-hole Hammer Hydraulic Rotary Rock Drill G150YF
-
Longye Brand Diesel Power Down-hole Hammer Hydraulic Rotary Rock Drill G140YF
-
Longye Brand Diesel Power Down-hole Hammer Hydraulic Rotary Rock Drill Z138YA
Product Details
| Condition | New | Type | Other | |
| Power Type | Diesel | Place of Origin | Shandong, China | |
| Brand Name | longye | Model Number | CTQ-Z138Y | |
| Usage | Ore | Voltage | 220v | |
| Power(W) | 45kw | Dimension(L*W*H) | 5200*1950*2300 | |
| Weight | 4170KG | Certification | CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CTQ-Z138YA hydraulic crawler down the hole drilling equipment /blasting hole drilling rig
CTQ-Z138YA type crawler quarry drilling rig, using a new hydraulic technology, with low air consumption rotary torque, variable-bit-shift hole easy The drilling rig compact structure, while promoting a retractable sliding shelf compensation, drilling when the sliding frame support on the ground, drilling and good stability. Use Z138 rig reliable Chazzan efficient drilling in hard rock drilling rig as fast as 2 times the low air pressure is the construction unit cost efficiency gains strong support.
The drilling rig is mainly suitable for open mining, water conservancy, power plants, road building and other Rock blasting whole drilling.
Main technical parameters of CTQ—Z138Y | |
Wind pressure (Mpa) | 0.7----1.6 |
Air consumption (m³/min) | 10----15 |
Drilling diameter (mm) | 90----130((max:203) |
Drilling depth (m) | level 40m,down 80m |
Once promotion distance (mm) | 3000 |
Drill diameter (mm) | 60 |
Skid compensation (mm) | 900 |
Maximum lift force (N) | 24900 |
Skid pitch (°) | up and down total 95 |
Swinging angle of skid (°) | Left 38, right 31 |
Boom Pitch (°) | up and down total 70 |
Boom swing angle (°) | Left 41, right 33 |
Grade ability (°) | 30 |
Chassis ground clearance (mm) | 260 |
Travelling speed (km/h) | 2 |
Back to the transit speed (r/min) | 0----80 |
Rotary torque (N.m) | 2000 |
Host Power (Kw) | 45 |
For rock (f) | 6----20 |
Impact frequency (r/min) | 950---1500 |
Total Weight (kg) | 3800 |
Dimension (L * W * H) | 5200*2030*2300 |
Note: The Company’s products continued to improve; various design and technical specifications may change at any time, without any additional notice or obligation.
