China No. 1 manufacturer ISO CE Powder briquette molding machine
Brief introduction of Powder briquette molding machine
Powder briquette molding machine is to regard the well processed all kinds of powder as raw material, after crush, mix, and then compress to different shape briquettes. The finished product can burn a long time, because of the holes, the surface of the coal briquettes are expanded, so that the coal briquettes can be easily and totally burnt, to reduce the waste of energy. The raw materials can be coal powder, charcoal powder, coke powder, carbon black powder, brown coal, many mineral powder, etc.
Characteristics of Powder briquette molding machine
1. The coal powder briquette machine simple structure convenient operation
2. Applicable raw materials: such as coal powder, coal dust, charcoal powder, coal ash, coal gangue, brown coal, breeze, furnace slag, coke powder, etc.
3. Through the coal powder briquette machine processing, finished products have a variety of shapes, and can be customized according to the requirements of customers
4. Multi-usage, energy-saving province electricity, the price is reasonable
5. High ratio of forming
6. The charcoal powder briquette machine has a strong production capacity
Technical Parameters of Powder briquette molding machine
Model |
MA140 |
MA160 |
MA180 |
MA220 |
MA260 |
Capacity(Punching times per Minute) |
45-50 |
45-50 |
45-50 |
20-24 |
20-24 |
Power(kw) |
7.5 kw; 4pole |
7.5 kw; 4pole |
11 kw; 4pole |
15 kw; 4pole |
15 kw; 4pole |
Presssure(tons) |
20-30 tons |
20-35 tons |
25-35 tons |
30-40 tons |
35-45 tons |
Mode of Operation |
Punching press |
Punching press |
Punching press |
Punching press |
Punching press |
Diameter Of Mould(mm) |
140 mm |
160 mm |
180 mm |
220 mm |
260 mm |
Diameter of Final Products(mm) |
Round:below140mm Square:100*100mm |
Round:below160mm Square:120*120mm |
Round:below180mm Square:150*150mm |
Round:below220mm Square:200*200mm |
Round:below260mm Square:220*220mm |
Height of Final Products(mm) |
30-90 MM; Can be adjusted |
30-90 MM; Can be adjusted |
30-90 MM; Can be adjusted |
30-90 MM; Can be adjusted |
30-90 MM; Can be adjusted |
Shape of final briquettes |
Round/square/hexagon/other shape with holes or without holes by customizing the related molds. |
||||
Materials Conditions |
Size: Less Than 5 MM ; Moisture: less Than 10% |
||||
The outlet briquettes
1. Shape: The briquette machine for carbon black can press the carbon black into diversified, pillow shape, oval shape,
egg shape, ball shape, column shape, square shape and so on. And the shapes and size of the briquettes can be customized.
2. Hardness: The finished product are very hard,they are not shattered even though down from 3 meters height.
3. Transport: It is very easy and convenient to transport either short transport or long transport.
The different molds
Product line of Powder briquette molding machine
Apart from the honeycomb coal briquette machine, other related machine such as feeder, grinder, crusher, conveyor and dryer are also available in our factory, it means we can offer a whole product line. In addition, we can help you with the installation.
Raw material-----Crushing -----Mixing-----Feeding-----Briquetting----Final briquette
Honeycomb charcoal briquette machine structure is simple, includes the body, drive, feeding, punching, and conveying, etc, five parts.
Packaging and shipping of Powder briquette molding machine
♦1. Our single charcoal honeycomb briquette machine will be packed in the wooden case with frame and steel base, which is fixed for shipping.
♦2. If the machines are lot, we will load them in the containers, like the pictures show. And the standard container is 20GP, 40GP, 40HQ.
♦3. We also can package and shipping the machines as your requirements.
◊Our customers
We are the manufacturer with over 30 years working experience.
Thanks for your interest in our machines, If you didn't get the suitable machine in this page, please email me your detailed requirement. Hope to have have the honor to cooperate with you in the bright future.
