HOT!HOT!high honor multifunctional Bamboo charcoal briquette machine
All kinds of briquette charcoal making machines
Note: Our factory has five types briquette charcoal making machines for your choice.
So in order to provide you the most suitable and your favorite briquette charcoal making machine, could you share me the following details? Thanks very much!
1) What's your raw material?
2) What's your favorite charcoal briquette's size and shape?
3) Do you need only briquette charcoal making machine or the whole line of briquette charcoal making machine?
Brief introduction of Bamboo charcoal briquette machine
The Bamboo charcoal briquette machine can press many different kinds of products (circle, square, irregular, etc). The finished product can be widely used in many fields, such as home cooking, steel industry and so on. Normal materials are charcoal powder, wood charcoal powder, coconut shell charcoal powder, rice husk charcoal powder, bamboo dust, charcoal dust etc. The raw materials all can be carbonized firstly, and then crushed into charcoal powder, then the Bamboo charcoal machine can be used for make charcoal briquette which is no smoking or smell and burning longer.
Characteristics of Bamboo charcoal briquette machine
1. Each Bamboo dust briquette machine can be equipped with many moulds by customizing the related shapes
2. High density, high hardness, not easy to broken
3. The finished products smokeless, smelless, clean and have a long burning time.
4. Abundant raw materials, low cost
5. CE BV ISO certificate
Main parameters of Bamboo charcoal briquette machine
Model |
MA140 |
MA160 |
MA180 |
MA220 |
MA260 |
Capacity(Punching times per Minute) |
45-50 |
45-50 |
45-50 |
20-24 |
20-24 |
Power(kw) |
7.5 kw; 4pole |
7.5 kw; 4pole |
11 kw; 4pole |
15 kw; 4pole |
15 kw; 4pole |
Presssure(tons) |
20-30 tons |
20-35 tons |
25-35 tons |
30-40 tons |
35-45 tons |
Mode of Operation |
Punching press |
Punching press |
Punching press |
Punching press |
Punching press |
Diameter Of Mould(mm) |
140 mm |
160 mm |
180 mm |
220 mm |
260 mm |
Diameter of Final Products(mm) |
Round:below140mm Square:100*100mm |
Round:below160mm Square:120*120mm |
Round:below180mm Square:150*150mm |
Round:below220mm Square:200*200mm |
Round:below260mm Square:220*220mm |
Height of Final Products(mm) |
30-90 MM; Can be adjusted |
30-90 MM; Can be adjusted |
30-90 MM; Can be adjusted |
30-90 MM; Can be adjusted |
30-90 MM; Can be adjusted |
Shape of final briquettes |
Round/square/hexagon/other shape with holes or without holes by customizing the related molds. |
||||
Materials Conditions |
Size: Less Than 5 MM ; Moisture: less Than 10% |
||||
Finished product of Bamboo charcoal briquette machine
After the processing of drying, compressing under the high pressure and temperature, the biomass briquette is characterized by high density, small in size, better combustion, capable as the substitute for the superior coal or firewood. This bio-fuel briquette is 40-80mm in diameter, occurs in the hollow quadrangular or hexagonal cylinder with a 15-20mm hole through the body.
The different molds
Bamboo charcoal briquette machine production flow
Charcoal dust –crusher-conveyor-mixer-conveyor-charcoal briquette press-final product
◊Delivering and Packaging of Bamboo charcoal briquette machine
1.Our single charcoal honeycomb briquette machine will be packed in the wooden case with frame and steel base, which is fixed for shipping.
2. If the machines are lot, we will load them in the containers, like the pictures show. And the standard container is 20GP, 40GP, 40HQ.
3. We also can package and shipping the machines as your requirements.
◊Our customers
We are the manufacturer with over 30 years working experience.
Thanks for your interest in our machines, If you didn't get the suitable machine in this page, please email me your detailed requirement. Hope to have have the honor to cooperate with you in the bright future.
