Widely Used Briquette Coal Gangue Ball Press Machine

Widely Used Briquette Coal Gangue Ball Press Machine photo-1
US$ 2,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
henan meshen machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Guangdong or other inland custom port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name henan meshen machine
Model Number CE
Voltage 220v, 380v, etc
Power(W) 11kw, 15kw, 18.5kw, 22kw, etc
Weight Accoeding to your type
Dimension(L*W*H) Accoeding to your type
Certification CE ISO
Warranty One year
After-sales Service Provided Engineers available to service machinery overseas



  Widely used briquette coal gangue ball press machine



Specifications

Coal gangue ball press machine

1 high quality

2. adjustable Initial Force

3. professional Technical

4. widely Used in Industry

Widely used briquette coal gangue ball press machine

Description of Coal gangue ball press machine
Coal gangue ball press machine can be used to compress the coal gangue powder , pulverized coal, iron powder, coking coal, aluminum powder, scrap iron and tin oxide, carbon powder, slag, gypsum, tailings, sludge, kaolin, activated carbon, coke, waste residue etc. Our factory can provide you single machine and complete set of equipment. The finished products are egg-shaped ball, oval-shaped ball, circular-shaped ball, square-shaped ball, columnar-shaped ball, banding-shape ball, cake-shaped ball, etc. Furthermore, apart from shapes mentioned above, we can also produce other various types based on customer requirements. Coal gangue briquette machine is suitable for the coal industry, chemical industry, metallurgy, building material, glass, ceramic, foundry industry such as addition of coal forming process of organic or inorganic binder, the main products include: coal gasification type coal, the boiler type, cold type coal, coal slurry forming, etc.

Widely used briquette coal gangue ball press machine

Widely used briquette coal gangue ball press machine

Widely used briquette coal gangue ball press machine



Main parameter of Coke powder briquette machine



   Type

   Capacity  (t/h)

    Roll Diameter (mm)

Pressure(t)

Roll Speed (r/min)

Power (kw)

Reducer

MC-290

1.5-2

290

18-20

15-17

5.5

ZQ290

MC -360

2.5-3.5

360

20

15-17

7.5

ZQ360

MC -400

4-5

400

22

15-17

11

ZQ400

MC-500(1)

6-8

370

24

15

15

ZQ500

MC-500(2)

8-10

500

25

15

22

ZQ650

MC -650

10-15

650

30

15

30

ZQ650

MC -750

15-20

750

34

13

30

ZQ750

MC -850

25-30

850

54

13

37-45

ZQ850

MC 1000(1)

35-40

1000

60

12

45-75

ZSY-355

MC 1000(2)

35-45

1000

77-240

10

75-90

ZSY-400

Shape and size of final briquettes: square, ball egg-shaped, round, oval, and column, strip-type, elliptic type,

pillow type and other special shapes by customizing the matching molds. Usurally 20-60mm.





The molds

Widely used briquette coal gangue ball press machine



Characteristics of Coal gangue ball press machine

1. Factory direct sale, professional manufacturer with over 30 years' product experience.

2. Reliable service

3. High-quality briquetting machine;

4. Various charcoal ball briquette press machines for your choice.

5. Easy operation and no flying dust

6. Smokeless, non-toxic, no peculiar smell, environment protective



Shape and size of final product

 Widely used briquette coal gangue ball press machine



The production line of Coke powder briquette machine

The process is: Crushing --> Mixing with binder --> Feeding --> Briquetting --> Drying.

 Widely used briquette coal gangue ball press machine





Packaging & Shipping of Coke powder briquette machine

Widely used briquette coal gangue ball press machine



Our Service

1) Pre-sale Service:

Design the suitable products and offer the reasonable consultation to meet your need by our engineer.

We can also offer experiment to test the equipment that the customer need.

2) After-sale Service:

On the spot guidance for installation by our engineers, and the buyer is responsible for the expense.

We have a perfect after-sales service system and team with professional and for whole using life.

  We are the manufacturer with over 30 years working experience.
Thanks for your interest in our machines, If you didn't get the suitable machine in this page, please email me your detailed requirement. Hope to have have the honor to cooperate with you in the bright future.
