2015 Latest Style Factory Supply Sand Crusher With CE & ISO Approved

2015 Latest Style Factory Supply Sand Crusher With CE & ISO Approved photo-1
US$ 98,900 - 180,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Production Capacity:
80-180 t/h
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Production Capacity 80-180 t/h
Place of Origin Henan, China
Brand Name HengJi
Model Number VSI-7611
Voltage 380 v
Power(W) 110 kw
Dimension(L*W*H) 3700*2150*2100 mm
Weight 7.8 t/h
Certification CE & ISO
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

2015 latest style factory supply sand crusher with CE & ISO approved

Description of sand crusher

Sand crusher is the latest product of authoritative experts from Germany, connecting with Chinese present working conditions. It’s the high—efficiency sand making equipment with advanced world levels in our country. It is the preferred equipment for artificial sand making and stone reshaping industry. It specially provides the best material for the highway, railway, high-rise buildings, municipal works, hydro-electric dam and concrete mixing station. It ranks first among similar products with its excellent cost performance and reliability.

2015 latest style factory supply sand crusher with CE & ISO approved2015 latest style factory supply sand crusher with CE & ISO approved



Feature of sand crusher

1, the structure is simple, the cost is low.



2, high efficiency and energy saving, crush with high efficiency.



3, finely and coarse grinding function.



4, moisture of material by the impact of small, water content of up to 8%.



5, in crushing hard, very hard material (such as corundum, sintered bauxite etc.).



6, product is a cube, little iron pollution.

2015 latest style factory supply sand crusher with CE & ISO approved

Working principle of sand crusher



When the material taken into the feed hopper, through the center feeding hole fall into the high-speed rotation of the rotor was sufficiently accelerated and by emission mouth out, first impact with a part of materials of the free falling after rebound, and then impact to the vortex shaped material around the vortex cavity lining (or counter block), is first bounced back to the top after the crushing cavity, partial steering movement, forming a continuous material curtain and launch out from the impeller material impact, finally through the lower part of the discharge port discharge.



Application of sand crusher



Sand crusher equipment can be used in Pebble,rock( the limestone, granite, basalt, aluminum, andesite, etc.), ore tailings, slags, artificial sand production. can be used in Building aggregate, highway, asphalt concrete and cement aggregate production.As well as stone reshaping production in water conservancy and hydropower engineering field,highway, railway, bridge, passenger line, airport runway, municipal engineering and high-rise buildings.finely process of mining areas. Building materials,mining,metallurgy, chemical industry,cement,abrasive,refractory material, etc.With high abrasive materials resistance and secondary disassembly, desulphuration of thermal power and metallurgy, slag and construction waste. Also can be used in the production of glass,quartz sand and other high purity material.



2015 latest style factory supply sand crusher with CE & ISO approved



Model parameter of sand crusher

there are a series of sand crusher to choose.



Model VSI-7611 VSI-8518 VSI-9526 VSI-1140
Capacity
(t/h)
Center and Sides Feeding 120-180 200-260 300-380 450-520
Center Feeding 60-90 100-130 150-190 225-260
Max. Feeding Size (mm) Soft Material 35 40 45 50
Hard Material 30 35 40 45
Rotation Speed(rpm) 1700-1890 1520-1690 1360-1510 1180-1310
Double Motor Power (kw) 110 180 264 400
Overall Dimension
L×W×H (mm)
3700×2150×2100 4140×2280×2425 4560×2447×2778 5000×2700×3300
Weight (t) 7.8 10.3 16 25.6
Vibrating Sensor Inspection Range: 0.1-20mm/s Continual Adjustment
Hydraulic Oil Pump Motor Power of Double Oil Pump(Kw) 2×0.31kw
Overall Dimension
L×W×H (mm)
820×520×1270
Power of Oil Tank Heater 2KW



Complete sand making line

2015 latest style factory supply sand crusher with CE & ISO approved

Manufacturing shop of sand crusher



Packaging & Delivery product



Export standard container 20GP OR 40GP,40HQ,the spare parts in wooden case for artificial sand crusher.





Our services about sand crusher



a. Installation and adjustment: Should the installation service is needed, technicist will be provided by supplier for buyer to assist the work such as welding connection of shell body.



b. Quality Guarantee: Three-guarantees of product and warranty period is one year.



c. Technical support is provided from the beginning to the end.



d. Spare parts are serviced for sale in the whole year.
