The best VSI vertical shaft impact crusher for making sand production line hot sale
- 100 Set / Sets per Month
- any port in China
- T/T Credit Card
- Tertiary Reversible Impact Hammer Crusher with High Chrome Blow Bar
- China Wheat and Grain Transport Vibrating Feeder Price in Shanghai
- Good Quality Heavy Hammer Crusher for Crushing All Kinds of Ores
- Sand Ore and Coal Vibrating Feeder Machinery Used in Mining Industry
- High Efficiency Stone Crushing Plant Impact Stone Crusher
- Sound Equipment Impact Crusher Machine for Stone Crushing Line
Product Details
Condition: | New | Type: | Impact Crusher | Application: | sand making |
Motor Type: | AC Motor | Power(W): | 380V | Capacity(t/h): | 60-520(t/h) |
Place of Origin: | Henan, China | Brand Name: | H-J brand | Model Number: | VSI/PCL |
Dimension(L*W*H): | 5000x2700x3300 | Weight: | According to different models | Certification: | ISO9001,CE |
Warranty: | 1year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
The best VSI vertical shaft impact crusher for making sand production line hot sale
Working Principle of Sand making machine introduce :
Center Feeding:Raw material falls down into feed hopper, then enters impellor through central entrance hole. It is accelerated in high-speed impellor, then is thrown out at speed of 60-75m/s. When hitting impact plate, it is crushed. Final products come downwards though outlet.
Ring Feeding:Raw material falls down into feed hopper, then through ring, it is devided into two parts by material-dividing plate. One enters into impellor through the center of material-dividing plate. The other falls down from outside of material-dividing plate. Material, which is thrown out by impellor at speed of 60-75m/s, hits material coming down from outside of material-dividing plate. In this way, material is crushed.
it is with higher capacity and much light in volumn. It is working with single electric motor.sand making machine sale applied for powder process of material product including metal and nonmetal ore, fireproof material, bauxite, diamond dust, architectural materials, artificial sand and all kinds of metal and ore materials.
specifaction :
Model | Max feeding(mm) | Power(kw) | Impeller speed(r/min) | Capacity(t/h) | Outer dimension(L*W*H) | Weight(t) |
VSI-600 | 40 | 160 | 1600 | 120 | 3670*1821*2100 | 6.5 |
VSI-800 | 60 | 200 | 1200 | 180 | 4037*2070*2375 | 8.5 |
VSI-1000 | 70 | 250 | 1000 | 240 | 4890*2386*2678 | 12 |
The whole production line:
The finished production:
Export standard container 20GP OR 40GP,40HQ,the spare parts in wooden case for artificial sand making machine
1) Pre-sale service:Freely provide project designing, process designing, choosing suitable equipment for you.
2) Medium-sales service: Accompany you to complete the acceptance of the equipment,draft the construction scheme and detailed process, and complete process of export.
3) After-sales service: We sent engineer to the scene to guide installation, debugging and training operators.
Q:Instalation
A:At the client’s request, hengji can provide installation Technicians to supervise and assist in the assembly and commissioning of the equipment. Travel and accommodation costs, plus US$50 per day per man to be met by the client.
Q:Payment
A:30% by TT as deposit on signing the contract, 70% by as final payment of balance after the client’s satisfactory inspection of the equipment prior to the goods leaving the hengji factory.
Q: What about Warranty? what will we do if the machine is broken down
A:The warranty period for all of hengji structural and mechanical equipment is one year. The warranty period for all
electric motors is half one year. Wear parts are not covered by warranty unless the component part is found to be flawed.
Q: What should we need to do for if we want to get a best quatation
1).the capacity (tons per hour )
spot inspection and operator traning according to your demands and the conditions of applied spot , we can help you choose the right equipments ,drilling rig ,loader ,trucks ,excavators and so on .
Q:What's your After sales sereive
A:All equipment manufactured by hengji is of the highest standard and very rarely have our clients experienced any mechanical problems. Should any problems occur, our team of Engineers and Technicians will respond within12 hours of notice by the client.
Q:Delivery time
A:Standard delivery time for stationary crusher plant is 30 days from receipt of deposit.the mobile crusher plant is 45 days,
Gongyi City Jinlong Heng Ji Heavy Machinery Co., Ltd. is a professional production of large and medium crushing, grinding, sand making equipment , research, production, marketing trinity of the private sector. Company headquarters is located in a blend of traditional and innovative mechanical Gongyi City Industrial Development Zone , over the years , the company adhering to the scientific management of modern enterprises , precision manufacturing , forge ahead , innovation, rapid rise to become the leader in equipment manufacturing deserved.
