CE standard sand machine/sand making machine with 160-380t/h
Vertical shaft impact crusher is of high power and low consumption. It is widely used in all kinds of mineral, cement, corhart, bauxite, carborundum grain, glass raw material, machine made construction sand, stone stock and all kinds of metallurgy slag, especially carborundum, sintered bauxite, magnesite, and very hard and anticorrosion materials. And Sand Making Machine is more productive than other kind of crushers.
Feature of sand machine
1, the structure is simple, the cost is low.
2, high efficiency and energy saving, crush with high efficiency.
3, finely and coarse grinding function.
4, moisture of material by the impact of small, water content of up to 8%.
5, in crushing hard, very hard material (such as corundum, sintered bauxite etc.).
6, product is a cube, little iron pollution.
Working principle of sand machine
The entire center feeding: Material falls the feed hopper, then enters the high-speed rotary sling wheel from center feeding hole, which is speeded immediately in the sling wheel. The speed can reach several dozens times of the gravity acceleration. Then it is thrown from the sling wheel. First, it is crushed with other rebounded material fell freely from the sling wheel. Then both of them are impacted to the material lining (rock-rock) or strike back block (rock-iron), rebounded and stroke to the top of eddy cavity in the inclined-up direction. Then it moves along deflection-down, and forms a continuous material curtain with the material from the impellers passage. Just like this, the material is stroke, rubbed, crushed twice or more, then is discharged from the down discharging hole.
Application of sand machine
1. sand machine is used for Pebble, rock( the limestone, granite, basalt, aluminum, andesite, etc.), ore tailings, attle artificial sand production.
2. sand making machine has been used in Building aggregate, highway, cushion, asphalt concrete and cement aggregate production.
3.Sand production and stone reshaping production in water conservancy and hydropower engineering field, highway, railway, bridge, passenger line, air new generation sand making machine port runway, municipal engineering and high-rise buildings.
4.The grinding anterior finely process of mining areas. Building materials, mining, metallurgy, chemical industry, cement, abrasive, refractory material, etc.
5.The crush of high abrasive materials resistance and secondary disassembly, desulphuration of thermal power and metallurgy, slag and construction waste.
6.The production of glass, quartz sand and other high purity material.
Model parameter of sand machine
A series of sand machine to be selected, you can choose a suitable models according to your capacity.
| Model | VSI-7611 | VSI-8518 | VSI-9526 | VSI-1140 | ||
| Capacity (t/h) |
Center and Sides Feeding | 120-180 | 200-260 | 300-380 | 450-520 | |
| Center Feeding | 60-90 | 100-130 | 150-190 | 225-260 | ||
| Max. Feeding Size (mm) | Soft Material | 35 | 40 | 45 | 50 | |
| Hard Material | 30 | 35 | 40 | 45 | ||
| Rotation Speed(rpm) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | ||
| Double Motor Power (kw) | 110 | 180 | 264 | 400 | ||
| Overall Dimension L×W×H (mm) |
3700×2150×2100 | 4140×2280×2425 | 4560×2447×2778 | 5000×2700×3300 | ||
| Weight (t) | 7.8 | 10.3 | 16 | 25.6 | ||
| Vibrating Sensor | Inspection Range: 0.1-20mm/s Continual Adjustment | |||||
| Hydraulic Oil Pump | Motor Power of Double Oil Pump(Kw) | 2×0.31kw | ||||
| Overall Dimension L×W×H (mm) |
820×520×1270 | |||||
| Power of Oil Tank Heater | 2KW | |||||
Complete sand line
Manufacturing shop of sand machine
Packaging & Delivery
Our Services about sand machine
a. Installation and adjustment: Should the installation service is needed, technicist will be provided by supplier for buyer to assist the work such as welding connection of shell body.
b. Quality Guarantee: Three-guarantees of product and warranty period is one year.
c. Technical support is provided from the beginning to the end.
d. Spare parts are serviced for sale in the whole year.
Sand machine is hot sale.As you konw,preferential prices tend to produce in communication.Welcome to visit our factory! Any more information you want to know, please contact me freely.
