Help CenterHigh Speed Double Layer A3 A4 Copy Paper Reel Cutting Machine
Related Products
-
660*1040mm Full Automatic Industrial Paper Folding Machine CombinedNegotiableMOQ: 1 Set -
Automatic Flat Creasing Die Cutting MachineNegotiableMOQ: 1 Set
-
Automatic Industrial Playing Cards Cutting Machine for Poker FactoryNegotiableMOQ: 1 Piece
-
Automatic Cardboard Die Cutting Creasing Machine For Packing BoxNegotiableMOQ: 1 Set
-
Electric Double Round Corners Paper Cutting Machine/Round Shape Paper Corner CutterNegotiableMOQ: 1 Set
Features
1. The whole machine is linked and protected by a SCM system,cutting length and speed are numerically controlled by computer. Easy adjustment.
2.It's drived by step motor(servo motor is optional). Panasonic Frequency converter control the cutting speed and paper feeding speed.
3. The cutting knife is welded with janpanese high speed steel, it is durable.
4. The paper feeder use pnuematic lifting system, the heavy roll can be easily loaded and unloaded.
5. Auto tension control system.
6. Auto sheet counter, when it get the presetted value the machine will alarm automatically.
7. The guided roller is specially processed to make sure the high cutting precision.
8. The circular knife trim the edge.
Main parameters
Model |
HPC2-450 |
Paper weight |
60-120gsm |
Cutting speed |
120m/min |
Cuttng width |
100-450mm |
Cutting length |
100-500mm |
Max roll diameter |
800mm |
Precision |
< ± 0.2mm/pcs |
Production rate |
30-150times/min |
Total power |
4.5kw |
