Woodworking Rotary Lathe
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
haiyong
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Veneer Rotary Peeling LatheUS$ 20,000 - 28,000MOQ: 1 Set -
BXQ1815 Spindlless Rotary LatheUS$ 7,500 - 14,000MOQ: 1 Set
-
Spindleless Veneer LatheUS$ 1,000 - 25,000MOQ: 1 Set
-
Log Peeling Spindleless Veneer LatheUS$ 1,000 - 15,000MOQ: 1 Set
-
Wood Rotary Peeling MachineUS$ 14,000 - 15,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
haiyong
Model Number
BXQ1815
Specifications
1.CNC Non-chuck rotary peeling lathe2.Cutting diameter 360mm
3.Cutting length 1300mm--2700mm
4.high efficiency
CNC Non-chuck rotary peeling lathe
Cutting diameter 360mm
Cutting length 1350-2600
This machine is used to peel the core veneer. With CNC control system and tool carriage feeding by servo motor control it has high precision, very popular for plywood industry.We independent development by our engineers.
Model | HX1815 | HX1822 | HX1827 |
Max cutting length (mm) | 1350 | 2000 | 2600 |
Max cutting diameter (mm) | Φ300 | Φ300 | Φ300 |
Log-core diameter (mm) | Φ26 | Φ26 | Φ26 |
Cutting thickness (mm) | 0.8-3.0 | 0.8-3.0 | 0.8-3.0 |
Veneer output speed (m/min) | 42 | 42 | 42 |
Power (kw) | 19.75 | 21.75 | 25.75 |
Overall dimension (mm) | 3320*1800*1260 | 3700*1800*1490 | 4585*1800*1560 |
N.W (kg) | 3500 | 5500 | 7000 |
