KCJB-S Intelligent Digital Magnetic Stirrer
Product features:
1.Single stirring mangnetic stirrer
2.accuratly digital display the speed.
3.Patented newest product ,adopts square 304 ss ,alluminium anti-corrosion processed above plate, can stir without heating or use water bath kettle to heat .
4.Using brushless DC motor , with stable performance ,low noise ,long service life , no spark .
5.The shell adopts one-time forming flame retardant strengthen PBT injection moulding shell, with thermostability,anti-corrosion and good insulation property.
6.30°cant control panel is suitable for standing and sitting viewing angle
7.Stepless speed adjustment,low speed-stable , high speed-strong
usage :
1.Fix the lever in the screw hole at the back and above of the instrument(attention :clockwise and counterclockwise ),adjust the hight of the cross clip then fasten the reaction bulb with the universal clip .
2.Adjust the “stir”knob clockwisely , make it in a right place according to speed showed to carry out stirring .
3.If the capacity is large or the solution is thick , you can increase the Stirring strength by adjust the knob .
4.If the phenomenon of jumping seed occurs , please turn off the stirring first and start slowly .
technical parameter :
Intelligent Digital Display Magnetic Stirring Plate 140mm × 140 mm
Model : KCJB-S
Voltage | 220v 50 HZ ( we can manufacture the 110 v ) |
Range of Speed | 0-2000 r / min |
Motor Power | 8W,DC14V |
Power(w) | 260 |
Accuracy | ±1°C |
Inner Wire | Cr20 Ni 80 |
Heating Dimension | 140mm × 140mm |
Stirring Flask Capacity | 50ml- 500ml |
Working time | Continuous |
External Dimension (mm ) | 265*155*120 |
Packing Size ( mm ) | 315*205*170 |
Weight ( kg ) | 2.2±0.2 |
Shell Material | To Spray Paint on the Superfine Plastic Once Only, anti-aging, anti-corrosion |
Intelligent Digital Display Magnetic Stirring Plate 180mm × 180 mm
Model : KCJB-S
Voltage | 220v 50 HZ ( we can manufacture the 110 v ) |
Range of Speed | 0-2000 r / min |
Motor Power | 8W,DC14V |
Power(w) | 350 |
Accuracy | ±1°C |
Inner Wire | Cr20 Ni 80 |
Heating Dimension | 180mm × 180mm |
Stirring Flask Capacity | 50ml- 2000ml |
Working time | Continuous |
External Dimension (mm ) | 325*215*120 |
Packing Size ( mm ) | 375*265*170 |
Weight ( kg ) | 4±0.2 |
Shell Material | To Spray Paint on the Superfine Plastic Once Only, anti-aging, anti-corrosion |
Intelligent Digital Display Magnetic Stirring Plate 230mm × 230 mm
Model : KCJB-S
Voltage | 220v 50 HZ ( we can manufacture the 110 v ) |
Range of Speed | 0-2000 r / min |
Motor Power | 40W,DC24V |
Power(w) | 600 |
Accuracy | ±1°C |
Inner Wire | Cr20 Ni 80 |
Heating Dimension | 230mm × 230mm |
Stirring Flask Capacity | 50ml- 5000ml |
Working time | Continuous |
External Dimension (mm ) | 430*270*150 |
Packing Size ( mm ) | 480*320*200 |
Weight ( kg ) | 7±0.2 |
Shell Material | To Spray Paint on the Superfine Plastic Once Only, anti-aging, anti-corrosion |
Intelligent Digital Display Magnetic Stirring Plate 280mm × 280 mm
Model : KCJB-S
Voltage | 220v 50 HZ ( we can manufacture the 110 v ) |
Range of Speed | 0-2000 r / min |
Motor Power | 40W,DC24V |
Power(w) | 7500 |
Accuracy | ±1°C |
Inner Wire | Cr20 Ni 80 |
Heating Dimension | 280mm × 280mm |
Stirring Flask Capacity | 50ml- 10000ml |
Working time | Continuous |
External Dimension (mm ) | 500*330*150 |
Packing Size ( mm ) | 550*380*200 |
Weight ( kg ) | 9.5±0.2 |
Shell Material | To Spray Paint on the Superfine Plastic Once Only, anti-aging, anti-corrosion |
attention :
1.Environmental temperature : 0-50°C without any corrosive air .
2.Relative humidity : 35%-85% no condensation
3.Over load is not allowed .
4.Instrument should be earthed well .
5.Long time no use ,please keep it clean and reserve it in a dry and without any corrosion air place .
When there is some change and difference about the specification which is caused by products or products reform related to the specification , pardon that we won’t inform you.
