Standard (Hotplate) Magnetic Stirrer

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KINGDAK		Model Number	MS-S
Place of Origin	Shanghai, China

Standard (Hotplate) Magnetic Stirrer

Features

A traditional magnetic stirrer with modern design
Stainless steel plates and with/without hotplate porcelain enamel surface
Variable speed of motor
Motor with electronic speed control, constant speed even during changes in load
High magnetic adhesion, prevent the stirrer bar escape
Enclosed assembly(IP42) and external rotor brushless motor guarantees long service time
Safe separate circuit, automatically stop to heat when the temperature over 350°C(MS-H-S)

Specifications

	MS-H-S	MS-S
Voltage [VAC]	100-120/200-240	100-120/200-240
Frequency [Hz]	50/60	50/60
Power [W]	530	30
Stirring point position quantity	1	1
Max. stirring quantity(H2O)[L]	20	20
Stirring point position quantity [mm]	80	80
Motor type	External rotor brushless motor	External rotor brushless motor
Motor rating input [W]	18	18
Motor rating output [W]	10	10
Speed range [rpm]	0-1500	0-1500
Speed display	Scale	Scale
Material	Porcelain enamel/Stainless steel	Porcelain enamel/Stainless steel
Dimension of Plate [mm]	φ135	φ135
Heating power [W]	500	--
Heat rate(1Lwater)[K/min]	6	--
Heating Temperature Range [°C]	RT-340	--
Temperature display	Analog Scale	--
Temperature display accuracy [°C]	350	--
Dimension [mm]	280×160×85	280×160×85
Weight[kg]	2.8	2.8
Permissible ambient temperature [°C]	5-40	5-40
Permissible relative humidity	80%	80%
Protection class acc. to DIN EN60529	IP42	IP42
