Specifications
1. Longer linning service life2. Low energy consuming3. Energy conservation and environment protection
The device is suitable for mineral processing, chemical, coal, cement, refractory materials, grinding and other departments to do
The series MQZ-type ball mill is a technical innovation
The characters of the tube energy-saving ball mill
The discharging part is designed as a cone type ,which increase the capacity and enforces the material at the discharging end to be reclassified, and the balls are reclassified too, that is the nearer to the end, the smaller are the balls ,increasing repeated milling effect.
Model |
Unit |
MQZ0909 |
MQZ0918 |
MQZ1224 |
MQZ1228 |
MQZ1530 |
MQZ1836 |
MQZ2442 |
Diameter Shell |
mm |
900 |
900 |
1200 |
1200 |
1500 |
1800 |
2400 |
Length Shell |
mm |
900 |
1800 |
2400 |
2400 |
3000 |
3600 |
4200 |
Revolution Shell |
r/min |
37.1 |
37.1 |
31.7 |
31.7 |
30.9 |
26.8 |
23 |
Effective Volume |
m3
|
0.45 |
0.9 |
2.2 |
2.5 |
5 |
12.6 |
16.2 |
Load of ball |
t |
0.9 |
1.5 |
3.96 |
4.24 |
8.6 |
23.5 |
31 |
Capacity |
t/h |
0.24-2.14 |
0.22-1.07 |
0.26-6.15 |
0.3-6.5 |
2.8-9 |
9-44 |
11-119 |
Power |
kw |
7.5 |
11 |
45 |
55 |
80 |
180 |
320 |
Weight |
t |
4.7 |
6.1 |
11.7 |
12.7 |
17.7 |
43.7 |
69 |
