Help CenterLeaching Agitation Tank/Agitation Tank/ Agitation Vat/Agitating Vessel/Washing Trommel/ Leaching Tank/Stirrer/Impeller Leaching
Related Products
-
Leaching Agitation Tank/Agitation Tank/ Agitation Vat/Agitating Vessel/Washing Trommel/ Leaching TankUS$ 1 - 9,000MOQ: 1 Set -
Laboratory Magnetic Separator/Experimental Magnetic Separator/ Small Size Magnetic Separator/New Style Laboratory Magnetic SeparUS$ 1 - 9,000MOQ: 1 Set
-
Lab Flotation Equipment/Small Size Mineral Processing Flotation Equipment/ Lab Mineral Processing Flotation Equipment/LaboratoryUS$ 1 - 9,000MOQ: 1 Set
-
Water Cyclone / Hydro Cyclone Unit/Polyurethane Hydrocyclones/Cyclone Hydrocyclone/JAX Polymer Hydraulic CycloneUS$ 1 - 9,000MOQ: 1 Set
-
Upright Pump/Vertical-Type Pump/Verticalpump/ump for Water -borne Solids Belt/Gravel PumpUS$ 1 - 9,000MOQ: 1 Set
The device is suitable for flotation, re-election, magnetic separation, etc. right concentration of not more than 35% and solid components of the slurry particle size of less than 1 mm to stir, but also can be used for flotation agents and other non-metallic minerals, mixing, so that mine suspended particles and in full access to the Pharmacy, mixing, in order to create conditions for sorting operations.
This series of stirred tank are the following: Agitating tank ,Lifting agitating tank,High concentration agitation tank, High efficiency agitation tank,Specifications of shemical agitation tank
Model |
U nit | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Diameter tank | mm | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Height | mm | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Volume tank | M3
| 0.124 | 0.25 | 0.58 | 1.15 | 2.2 | 4.4 | 11.2 | 19.1 | 46 |
Impeller Diameter | mm | 150 | 240 | 240 | 310 | 400 | 550 | 630 | 700 | 1000 |
Impeller speed | r/min
| 1000 | 530 | 530 | 492 | 320 | 230 | 230 | 210 | 121.6 |
Power | kw | 1.1 | 1.5 | 1.5 | 2.2 | 3 | 5.5 | 7.5 | 7.5 | 30 |
Weight | kg | 260 | 320 | 480 | 908 | 1280 | 1760 | 2700 | 18.5 | 8020 |
