Home > Manufacturing & Processing Machinery > Feeder > Vibrating Feeder > Self Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/ig Feeder

Self Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/ig Feeder

Self Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/ig Feeder thumbnail-1
Self Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/ig Feeder thumbnail-2
Self Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/ig Feeder thumbnail-3
Self Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/ig Feeder photo-1
Self Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/ig Feeder photo-2
Self Feeder/ Feeding Equipment/Tilting Cup Feeder/Swaying Feeder/ig Feeder photo-3
US$ 1 - 9,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Use mine
Power Type:
Electric
Contact Supplier Request Quote Chat Now
Shicheng Oasis Mineral Equipment Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
GuangZhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Use mine
Power Type Electric
Capacity(t/h) 5 t/h
Place of Origin Jiangxi, China
Brand Name OASIS
Model Number 400/300
Power(W) 3000
Dimension(L*W*H) 2820*800*600
Weight 790KG
Certification ISO9001:2008
Warranty One year
After-sales Service Provided Overseas service center available

Specifications

1. Smoothly vibrating, long service life.2. Adjustable vibrating force and flow of materials.3. Low noise and power consumption.

Trough to the mining machine and the Pendulum feeder for mineral processing, coal, chemical industry and other sectors will be granular and massive materials sent out from the storage silos by a variety of different types of feed devices, but not suitable for conveying ore powder and other powder materials.
This machine can be used as ball mill and the mine belt conveyor continuous and uniform supply of granular material feed set



Model



Unit

400/300

600/500

980/1240

1000/1900

1060/2900

Feed size

mm

50

205

300

300

350



Frequency bottom back and forth

r/min

18.5

18.9

24

27

30

Crank Stroke

mm

0-50

0-50

0-50

0-125

0-125

Capacity

t/h

0-5

10-50

36-90

200-300

400-900

Power

kw

3

4

7.5

11

25-40

Overall dimensions

mm

2820/800/600

2700/900/850

3560/1000/1000

3900/1590/1350

4580/2950/1750

Weight

kg

790

1050

1700

2690

3200
