Dressing Machine/Concentrating Machine/Ore Dresser Machine/Dresser Machine/ Beneficiation Machine
1. Drum, spiral and other major parts available corrosion of stainless steel, titanium alloy
2. Rotary spray delivery conveyor can be wear-resistant alloy or carbide inserts welded sheet
3. Speed variable speed drum
4. Screw adjustable differential speed, there are very or stepless
5. Simple and reliable lubrication
6. Security: speed detection, vibration protection, motor thermal overload protection, zero differential speed spiral
7. For high viscosity materials, can use hydraulic differential, stable and reliable
8. All products through the ISO certification
Gold water set of centrifuge is centrifugal force according to law, in the traditional centrifuge based on development and improvement of a kind of energy saving equipment out, easing inhaled effect, make the heavy ore mineral grains get full settlement, greatly improve the equipment to choose than ability and don't recovery, recovery can reach more than 90. Homework recovery improve Sn: 3.01%, W: 5.5%, Pb: 1.63%, Zn, 2.04; Water consumption decreased by 30%-40%, cover an area of an area decrease 1/3, and stroke can be adjusted, due to the electromagnetic control motor on the adjustment, make the flush times stepless adjustment. Its performance meet the domestic advanced level, is the ideal energy saving heavy choose one of the equipment. Because of its capacity, choose don't size range wide, simple operation and maintenance, as cyclones or select is widely used to choose don't au, sn, tungsten, titanium, red iron, etc.
model |
STLB20 |
STLB30 |
STLB60 |
capacity (T/h) |
0-0.6 |
2-3 |
8-12 |
Slurry water (m3/h) |
2-3 |
3-5 |
7-10 |
|
back wash water (m3/h) |
1.5-4 |
5-7 |
8-12 |
density(%) |
0-50 |
0-50 |
0-50 |
size(mm) |
0-3 |
0-3 |
0-5 |
Row ore cyclev |
mountain gold 1-3/h,sand gold 2-6/h |
||
Output concentrate (Kg) |
2 |
3-5 |
10-20 |
power (Kw) |
0.75 |
1.5 |
4 |
|
Machine weight (kg) |
205 |
380 |
1100 |
|
contour dimension (mm) |
914×700×900 |
1160×885×1165 |
1820×1450×1700 |
