Hydraulic classifier
Hydraulic classifier sieve-type groove, also known Code watts (Denver)-type hydraulic grader, is the use of sieve-plate subsidence caused by interference in terms of equipment. The body shape for the corner of the cone-shaped boxes, boxes with vertical partitions into 4 ~ 8 graded rooms. Each room off an area of 200mm × 200mm. Away from the room at the end of a certain height to set sieve.
Sieve-plate-type hydraulic classifier has the advantage of simple structure, no momentum. With mechanical agitation hydraulic classifier comparison, a high degree of small, easy to configure. Select plants according to the different processing capabilities, made of four rooms, six rooms, 8 rooms of different specifications. This grading machine in our small and medium sized concentrator used more often.
The equipment used for sorting 2.5-1.5 iron, tungsten, tin, gold, etc. and non-ferrous, ferrous metal mine use
Model |
Feed size (mm) |
Feed density |
Increase in water pressure |
Ethmoid Size (mm) |
Capacity t/h |
Overall dimensions (mm) |
240×240 |
0—3 |
20%~ 26% |
150~ 200 |
240×240 |
5—8 |
1818×1138×1680 |
