Desliming Doo
Desliming the Big Dipper is also called cone classifier is a simple classification, de-sludge and enrichment equipment. It is an inverted cone shape. Center set up at the surface to the mine cylinders, cylinder bottom edge confiscated a number of depth below the liquid level. Along the tangent direction of the pulp into the center to the cylinder, buffered by the outflow from the bottom edge. Radial outflow of the pulp overflow weir to the surrounding flow. In this process, the settling velocity greater than the flow rate of increase in sub-coarse particles will be submerged in the tank, and discharged through the bottom of the Grit Chamber. With the surface of fine particles into the overflow tank into the pulp. To the ore particle size is typically less than 2mm. Graded finer granularity of 75μm or more.
Sub-mud bucket with a simple structure, easy to manufacture, do not consume power and so on. As the cone volume larger storing in the production process there is mineralization. Is currently mainly used in hydraulic grading machine before the ore to de-mud, so as to enhance the efficiency of classification; and also installed equipment in the grinding of ore prior to enrichment, dehydration, to enhance the grinding machine to the ore concentration; also used in the various kinds of sludge pre-sorting equipment control to the amount of ore and mineral concentrations.
Can be designed according to user needs.
Design specifications are: the amount of discharge 10-200t / h
Diameter: mm |
Settlement area: square |
Capacity: Cubic |
Pai Mining Pipe: mm |
Feeding size: mm |
Processing capacity: t / h |
By mine management: mm |
Weight: Kg |
1000 |
0.75 |
0.27 |
25 |
0.2 The following |
4.5-52 |
|
500 |
1500 |
2 |
0.83 |
40 |
0.2 The following |
4.5-52 |
|
980 |
2000 |
3 |
2.27 |
50 |
0.2 The following |
4.5-52 |
150 |
1483 |
2500 |
4.9 |
4 |
60 |
0.2 The following |
4.5-52 |
150 |
1850 |
3000 |
7 |
6.65 |
70 |
0.2 The following |
4.5-52 |
150 |
2100 |
Note; |
Pai ore concentration of 40-60%, 33-45% removal efficiency of mud |
||||||
