Home > Products > Small screen > Drum (sieve) screen
Drum (sieve) screen
- 200 Set / Sets per Month
- XiaMen
- T/T
Product Details
Condition: | New | Type: | Circular | Application: | Ore |
Place of Origin: | Jiangxi, China | Brand Name: | OASIS | Model Number: | SGT1015 |
Voltage: | 380V | Power(W): | 4000 | Dimension(L*W*H): | 3000/1400/2135 |
Weight: | 2200kg | Certification: | ISO9001:2008 | Warranty: | One year |
After-sales Service Provided: | Overseas service center available |
Product Description
Specifications
1. Adaptability for fluctuation of feeding grain size and feed density (solids)aareliable working2. Easy operation
Sieve cylinder is consisted by roller ,frame, funnel, reducer and motor five parts. Mineral flow into roller, on the one hand, along with roller rotation and be screening, on the other hand ,size large ore or stone roller Angle away along the forward, through the different screen was gradually the sun drying out, not big stone after the sieve out into funnel, then shipped or their)
Just sieve drum strong, durable, steel to do just by welding, funnel of large volume, for steel welding and become, with many funnel, funnel mouth and for the connection, but to the side or a side, easy to LaYun, their and improve the production, can prevent wear screen, a single mistake production
Mainly applied to adapt to all kinds of nature of screening materials: sand gold mine, coal, coke, lime and damp easily blocked material, the largest screen products less than 100 mm, among 10-50 mm, the finest of less than 3 mm, the biggest feeding grain size of 200 mm
model | capacityt/h | electrical machine kw | Diameter mm | Length mm | Under the screen size mm | overall dimension mm | Weight kg |
SGT1015 | 50 | 4 | 1000 | 1500 | 3-10 | 3000/1400/2135 | 2200 |
SGT1020 | 100 | 5.5 | 1000 | 2000 | 3-10 | 3460/1400/2100 | 2800 |
SGT1225 | 160 | 7.5 | 1200 | 2500 | 3-10 | 4140/1600/2600 | 4200 |
SGT1530 | 250 | 11 | 1500 | 3000 | 3-10 | 4460/1900/2800 | 5100 |
SGT1545 | 350 | 15 | 1500 | 4500 | 3-10 | 5900/1900/3000 | 6000 |
SGT1848 | 450 | 22 | 1800 | 4800 | 3-10 | 6500/2300/4000 | 7500 |
SGT2055 | 600 | 30 | 2000 | 5500 | 3-10 | 7500/2500/400 | 8600 |
