Magnetic Separator /Magnetic Ore Separator/Wet Drum Separator

FOB Price

US$ 27,200 - 27,300 / Set

1 Set(Min. Order)

Port Xiamen
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Magnetic Separator
Production Capacity	0.5-1 t/h	Place of Origin	Jiangxi, China
Brand Name	oasis	Model Number	400/400
Voltage	380 V	Power(W)	1100
Weight	301 kg	Certification	ISO9001:2008
Warranty	One year	After-sales Service Provided	Overseas service center available

Product Description

Specifications

1. Wet separating2. High and low intensity magnetic field3. Magnetic separation relative equipment

Monocular wet to do a half turn counter-current Magnetic wet drum separator for semi-backflow tank
The CTB / S / N magnetic separator is mainly used for wet weak magnetic sorting or remove fine particles strong magnetic minerals, widely used in mineral processing, coal preparation and chemical industries. In the wet magnetic separation operations, if the access to clean magnetic minerals, usually selected downstream-type magnetic separator (for less than 6 mm); if required to maximize the recovery of magnetic minerals, then the selection of reflux-type magnetic separator (for less than 0.8 mm); when the drug taking into account the grade and recovery of magnetic minerals, when to use semi-reflux separator (for less than 1 mm), magnetic field strength from 100 gauss to 6800 gauss between the
1 Tesla (T) = 1000 mT (mT) = 10000 gauss (Gs)

Model	Diameter	Tube	Magnetic induction density	Speed	Partide sorting	Capacity		Power	Weight
Model	mm	mm	Mt	r/min	mm	t/h	m3/h	Kw	kg
400/400	400	400	100-600	48	0.8-6	0.5-1	1.5-3	1.1	301
400/900	400	900	100	48	0.8	2-5	6-12	1.1	468
500/600	500	600	100	44	0.8	3-7	9-21	1.5	423
500/1200	500	1200	100	44	0.8	5-15	15-45	1.5	711
600/900	600	900	100	39	0.8	8-15	24-45	2.2	678
600/1200	600	1200	100	39	0.8	10-20	30-60	2.2	846
750/900	750	900	100	35	0.8	10-25	30-75	2.2	736
750/1800	750	1800	100	35	0.8	20-45	60-135	3	1268
900/1800	900	1800	100	31	0.8	25-55	75-165	4	1456
1050/2100	1050	2100	100	22	0.8	45-88	135-264	5.5	2006
1200/2400	1200	2400	100	19	0.8	65-100	195-300	7.5	3968
