DLS pulsating high gradient magnetic separation machine

FOB Price

USD $125,500 - $535,000 / Set

1 Set(Min.Order)

Supply Ability 260 Set / Sets per Month
Port Xiamen
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Magnetic Separator
Production Capacity	0.05-0.25 t/h	Place of Origin	Jiangxi, China
Brand Name	oasis	Model Number	DLS-50
Voltage	0-12 V	Power(W)	0-16000
Dimension(LWH)	1800/1400/1320	Weight	2 t
Certification	ISO9001:2008	Warranty	One year
After-sales Service Provided	Overseas service center available

Product Description

DLS pulsating high gradient magnetic separation machine is best and technology at home and abroad and performance of the most advanced strong magnetic separation equipment, the aircraft from the fundamental solution to the flat ring strong magnetic separation machine peace ring the high gradient magnetic medium easy to jam the world technical problems, it has a big, enrichment ratio to feed size, concentration and grade fluctuation adaptable, reliable and convenient operation and maintenance, the weak magnetic separation ore concentrate grade and realized the high recovery of high analyzed advantages

Flat ring the high gradient magnetic separation machine to feed size demand is strict, we studied the unique magnetic system structure and optimized combination of magnetic medium, make DLS magnetic separation machine feed size limit of 2.0 mm

specifications		DLS-50	DLS-75	DLS-100	DLS-125	DLS-150
ring diametwer(mm)		500	750	1000	1250	1500
rotating speed of ring(r/min)		0-4	0-4	0-4	0-4	0-4
ore-feeding size (mm)		-1.0 (30~100)	-1.0 (0.3~100)	-1.3 (30~100)	-1.3 (30~100)	-1.3 (30~100)
ore-feeding concentration(%)		10~40	10~40	10~40	10~40	10~40
slurry put through(m³/h)		0.5~1.0	1.0~2.0	12.5~20	20~50	50~100
Dry mineral processing capacity(t/h)		0.05~0.25	0.1~0.5	4~7	10~18	20~30
background field(T)		0~1.1	0~1.1	0~1.1	0~1.1	0~1.1
energizing current(A)		0~1300	0~1200	0~1050	0~1000	0~1050
energizing voltage(V)		0~12	0~17	0~27	0~35	0~42
energizing power(KW)		0~16	0~20	0~28	0~35	0~44
Swivel ring power(KW)		0.18	0.55	1.1	1.5	3
pulsating power(KW)		0.37	0.75	2.2	2.2	4
pulsating stroke (mm)		0~50	0~50	0~30	0~20	0~30
pulsating frequency (r/min)		0~400	0~400	0~300	0~300	0~300
water pressure (mpa)		0.1~0.2	0.1~0.2	0.2~0.4	0.15~0.3	0.2 ~0.4
water consumption (m³/h)		0.75~1.5	1.5~3.0	10~20	30~50	60~100
machine weight(t)		2	3	6	14	20
weight of heaviest part(t)		0.5	0.7	2	4	5
overall dimension	length(mm)	1800	2000	2700	3200	3600
	wide(mm)	1400	1360	2000	2340	2900
	high(mm)	1320	1680	2400	2700	3200
