Dressing Machine/Concentrating Machine/Ore Dresser Machine/Dresser Machine/ Beneficiation Machine/Lab shaker6S

Specifications

laboratory shaking table features:
High quality, precision manufacturing
High quality of concentrates produced, high recover

laboratory shaking table features:
High quality, precision manufacturing
High quality of concentrates produced, high recovery

Laboratory shaking table is smaller than the ordinary shaking table, is one of the commonly used equipment to conduct gravity concentration for feasibility study and test of ores for labs and beneficiation plant. It is not only widely applied on separating Gold, Tungsten, Tin, Manganese, Iron, Titanium, Zircon, Tantalum, Barium, Chrome, Lead, Zinc, Mercury, Copper, Aluminum ,and other rare metals and the noble metal ore, also applied on sorting coal. It can carry out ore concentration operation independently and also can operate in conjunction with jig, spiral separator, centrifugal separator and other equipment. The performance is also the same as the ordinary shaking table.



Laboratory Shaking Table is to make separations based on the difference of specific gravity of feed materials, reciprocating asymmetrical movement and the stratification performance of the inclined table surface in the lateral water flow with obvious zone of the minerals with different specific gravities on the table, high quality of concentrates produced, high recovery, convenient operation and adjustment and other features.



 Laboratory shaking table Technical Parameters

Model		6-S 3000×1620	6-S 2100×1050	LY 1100×500
Deck Size	Length(mm)	3000	2100	1100
	Transmission end width(mm)	1620	1050	500
	Concentrate end width(mm)	1110	850	430
Beneficiation Area(m2)		4.08	2	0.51
Feeding Particle Size (mm)	Coarse sand Deck	2-0.5	2-0.5	2-0.5
	Fine sand Deck	0.5-0.1	0.5-0.1	0.5-0.1
	Slime Deck	0.1-0.037	0.1-0.037	0.1-0.037
Feeding Amount (t/h)	Coarse sand Deck	0.6-1.5	0.4-0.8	0.1-0.2
	Fine sand Deck	0.3-0.8	0.2-0.5	0.05-0.1
	Slime Deck	0.2-0.4	0.1-0.2	0.03-0.05
Feeding Density (%)		10-30	10-30	10-30
Water Added (t/h)		0.3-1.5	0.2-1	0.1-0.5
Stroke (mm)		10-30	12-28	9-17
Frequency (F)		240-420	240-450	280-460
Transverse slope of Deck		0°-8°	0°-10°	0°-10°
Motor	Model	Y100L-4	Y90L-4	Y80L-4
	Power (kw)	1.1	1.1	0.55
Weight (t)		550	350	150
