Specifications
ShiCheng Oasis Mineral Equipment Manufacturing Co., LTD(0086-13697077005)is productionMain applicat
ShiCheng Oasis Mineral Equipment Manufacturing Co., LTD(0086-797-5745599)is production
Main application areas:
Colleges, universities and research institutes to conduct non-ferrous mineral processing laboratory, black, a selection of rare metal ore
A variety of non-metallic mineral sorting experiments
Scattered scrap metal powder, fine-grained, and other insulating materials, sorting
Plastics Removal of non-ferrous metals
Municipal solid waste recovery for copper, aluminum and other valuable metals
Selection of food and other grains to remove debris impurity
Corona and electrostatic field with a combination of complex electric field
Drums speed, great distance, selected angle (electrode angle relative to the drums), voltage, to the mine
Groove angle and amplitude, etc., when in operation can be adjusted
To the ore bucket temperature, drum temperature can be controlled
Main technical parameters and specifications Model | |
Drums (diameter mm × Length mm) |
250×200 250 × 200 |
Feeding size (mm) |
0.04-1 0.04-1 |
Processing capacity (kg / h) |
15-30 15-30 |
Maximum voltage (kv) |
60 60 |
Dimension (mm) |
925 ×1126×1850 |
