Technical Parameter of laboratory XFD Single Flotation Cell
XFD Series Single Flotation Cell is provided for flotation of minor ore samples in labs of geological,metallurgical,chemical and other industries. The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Mineral Resources,in compliance with the Industrial standards
XFD second-generation new product has a variable frequency technology, digital display, adjust the precise, reliable operation and so on.
XFD third-generation new product has a variable frequency technology, digital display, adjust the precise, reliable operation characteristics, and the other heat pipes, temperature control device, at any time control, display tank mine fluid temperature, plus automatic adjustment of fill with water, automatic drug delivery devices such as
Model | Volume of tank | Impeller diamete | Impeller speed | Scraper speed | Power | Overall dimensions | Weight |
Granularity for 0.2 mm | L | mm | r/min | r/min | w | mm | kg |
XFD0.5L | 1.5 | 45 | 2130-2590 | 15/30 | 90 | 635/338/700 | 30 |
XFD0.75L | 0.75 | 45 | 2130-2590 | 15/30 | 90 | 635/338/700 | 30 |
XFD1L | 1 | 55 | 1700-2100 | 15/30 | 90 | 635/338/700 | 30 |
XFD1.5L | 1.5 | 60 | 1590-1910 | 15/30 | 90 | 635/338/700 | 33 |
XFD3L | 3 | 70 | 1544-1890 | 8/20 | 120 | 683/350/822 | 50 |
XFD8L | 8 | 100 | 1400 | 8.6/13/17 | 250 | 740/350/867 | 71 |
