ShiCheng Oasis Mineral Equipment Manufacturing Co., LTD(0086-797-5745599
PE100 Jaw Crusher Series are widely used for many kinds ore.
Main Application Fields:,
PE100 Jaw Crusher Series are mainly applied in ore,coal, magnetic material, synthetic diamond, iron alloy, non-metallic material, artificial sand making, oil and chemical material these powder making projects.
Features:
· PEF100series---a complex swing fine crushing jaw crusher
· curved ultra deep crushing chamber
· even liner
· high crushing efficiency and low consumption
· homogeneous output size
· effective air protection or dustproof to crushing material
· no any other basic requirement for installation except on level ground.
Technical Specification
Main Technical Parameters and Models | |||
Model | PE100×125 | PEW100×250 | PEW100×125 |
Size of feed inletmm | 100×125 | 100×250 | 100×125 |
Maximum feeding sizemm | 85 | 85 | 85 |
Discharging sizemm | 0.5~6 | 0.5~8 | 0.5~6 |
Processing capacitykg/h | 50~800 | 400~1800 | 50×800 |
Motor powerkW | 3 | 4 | 3 |
Overall dimensionmm | 700×500×1400 | 950×950×1750 | 700×500×700 |
Total weightkg | 390 | 850 | 430 |
Remarks | Hermetic and inert gas can be filled to protect material oxidizing. Customers can order the environmental friendly with a dust wiper | Customers can order the environmental friendly with a dust wiper | |
