Our feeder series have two types: vibrating feeder and linear feeder.
Vibrating feeder series have two engines. Users can adjust vibrating frequency of feedr freely so as to completely control feeding speed of stone material and ensure smooth operation of production line. Linear feeder has features of stable vibration,reliable operation and long service life, can feed crushing machine continuously and has primary sieving on materials.
It is widely used in crushing and screening plants of mining,construction materials,silicate and chemical industry.
Vibrating Feeder Technical Data
Model | Max input size (mm) | Capacity | Motor power (kw) | Installaition Slope | Weight | Size of Funnel (mm) | Overall Dimension (mm) |
GZD-180×80 | 300 | 30-80 | 2×1.5 | 0-10 | 0.8 | 1800×800 | 2200×1100×800 |
GZD-200×120 | 300 | 80-500 | 2×2.2 | 0-10 | 0.9 | 2000×1200 | 2000×1200×855 |
GZD-300×90 | 300 | 40-100 | 2×2.2 | 0-10 | 1.5 | 3000×900 | 3050×1430×1550 |
ZSW-380×96 | 500 | 90-200 | 11 | 0° | 3.98 | 3800×960 | 3882×2224×2121 |
ZSW-420×110 | 580 | 150-350 | 15 | 0° | 5.0 | 4200×1100 | 4250×2500×1365 |
ZSW-490×110 | 580 | 180-380 | 15 | 0° | 5.32 | 4900×1100 | 4957×2500×1365 |
ZSW-490×130 | 750 | 250-450 | 22 | 0° | 5.9 | 4900×1300 | 4957×2580×2083 |
ZSW-600×130 | 750 | 450-800 | 50 | 0° | 7.8 | 6000×1300 | 6082×2580×2083 |
ZSW-600×150 | 800 | 600-1000 | 30 | 0° | 8.67 | 6000×1500 | 6082×2660×2400 |
