DL90CM Sevro Saving Energy Plastic Injection Molding Machine
Features Specifications
| Machine Type | DL90CM | |||
| Unit | A | B | C | |
| Injection Unit | ||||
| Screw Diameter | mm | 32 | 36 | 38 |
| Screw L/D Ratio | 22.5 | 20 | 18.9 | |
| Swept Vloume | c.c. | 140 | 178 | 198 |
| Shot Weight(PS) | g | 128 | 162 | 181 |
| oz | 4.5 | 5.8 | 6.5 | |
| Injection Pressure | Mpa | 203 | 160 | 144 |
| Injection Speed | mm/sec | 99 | 99 | 99 |
| Injection Rate | c.c./sec | 75 | 95 | 106 |
| Plasticizing Capacity | kg/h | 20 | 28 | 33 |
| Screw Speed | r.m.p | 200 | ||
| Screw stroke | mm | 175 | ||
| Clamping Unit | ||||
| Clamping Type | Five-Piont Double Toggles | |||
| Clamping Force | KN | 900 | ||
| Opening Stroke | mm | 300 | ||
| Max.mold height | mm | 350 | ||
| Min.mold height | mm | 150 | ||
| Space Between Tie-Bar | mm | 355x350 | ||
| Max.mold thickness | mm | 350x350 | ||
| Min.mold thickness | mm | 250x250 | ||
| Ejector Stroke | mm | 85 | ||
| Ejector Force | KN | 25 | ||
| Number Of Ejector | pcs | 1 | ||
| Others | ||||
| System Pressure | Mpa | 16 | ||
| Electric Motor | kW | 11 | ||
| Heating Pump | kW | 7 | ||
| Number of temp control zones | 3+1 | |||
| Oil Tank Capacity | L | 200 | ||
| Machine Dimensions | mm | 3.6x1.0x1.7 | ||
| Machine Weight | ton | 2.8 | ||
About Our Company:
Dalian Mach Co., Ltd. specializes in exporting all kinds of machinery such as Metal Processing Machines, Paper Processing Machines, Packaging Machines, Rubber Machinery, Pharmaceutical Machines, Daily Product Making Machines and Forklifts. With more than twenty years' experience, our professional team will provide best service for you.
We have a group of professional engineers in charge of technology, manufacturing, installing and testing, so we can guarantee that our machines will put on good performance based on high quality.
Our products have been exported to more than 60 countries such as Canada, the U.S.A., Italy, France, Guatemala, Brazil, Bolivia, Chile, Russia, Romania, Saudi Arabia, Syria, Jordan, the U.A.E., Indonesia, Singapore, Thailand, India, Pakistan, South Africa, Egypt, Nigeria, Kenya and Ghana.
We sincerely hope to establish a long-term cooperative relationship with you and become your true partner when you need our service.
...
