CKE6150Z DMTG CNC Lathe China factory

Name: CKE6150Z DMTG CNC Lathe China factory
Brand: DMTG
Availability: InStock

FOB Price

US$ 16,500 - 20,000 / Unit

1 Unit(Min. Order)

Port Dalian Port China
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	500mm	Place of Origin	Liaoning, China
Brand Name	DMTG	Model Number	CKE6150Z
Voltage	380V or 220V	Power(W)	7.5KW
Dimension(LWH)	2800x1750x1620mm	Weight	2800kgs
Certification	CE	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

CKE6150Z DMTG CNC Lathe China Factory

With FANUC 0i mate TD control system

With Siemens 802C/828D control system

With FAGOR 8055i control system

With GSK control system

Main Specification:

Model	CKE6150Z
Max. swing over bed (mm)	500
Width of bed	400
Max. length of work piece (mm)	750/1000/1500/2000
Max. swing over slide (mm)	280
X travel (mm)	280
Z travel (mm)	680/930/1430/1930
Spindle nose	D8
Chuck size (mm)	250
Taper of spindle bore	1:20
Spindle bore (mm)	82
Steps of spindle speed	3-step actuator (7-135rpm; 30-550rpm; 110-2200rpm )
Frequency conversion motor power (kW)	7.5
Rapid traverse X/Z (m/min)	41435
Repeatability of tool post (mm)	0.008
Vertical 4-position Tool post changing time (s)	2.4
Horizontal 6-position Tool post changing time	3
Diameter of tailstock quill (mm)	75
Travel of tailstock quill (mm)	150
Taper of tailstock quill	M5
Net weigh (kg)	2550/2600/2700/2800
Overall dimensions (mm)	2580×1750×1620
	2830×1750×1620
	3330×1750×1620
	3830×1750×1620

Standard accessories

Inverter motor control spindle ( automatic changes )

Concentrated lubrication device ( can be controlled by programs )

Headstock independent lubricate system

3-jaw chuck

Coolant system

Vertical 4-Station Electric Turret
Oil Gun
Tool Kit

90 degree movable control console

Operation manual

Optional accessories
4-jaw chuck Dia: 400mm

Steady rest Dia:30-200mm

M5 Live Center

Horizontal 6-Station Turret

250mm hydraulic chuck (through-hole)

Hydraulic Station

Hydraulic Tailstock

CE electrics

Door interlock

Anti-vibration pads

About our company:

Founded in 1948, Our factory entered the top 8 machine tool builders in the world. turly a leader in the machine tool industry worldwide. Our CNC lathe sell to more than 100 countries and regions worldwide.

...
