Introduction of Briquetting Machine:
This is a kind of screw briquetting press and it can be used to produce hexagonal or quadrangular cylinder. There is a hole (15-20mm) throughout the finished biomass briquettes. Since they can be stacked, compared with wood chips, wood briquettes are more convenient to store. The reason why briquettes are more efficient when burning is that the central hole and outer layer are carbonized during the briquetting process. GCBA series briquetting press is designed with automatic temperature control system which makes it a good choice for pressing hard wood materials such as rich husk and sawdust. The appropriate electric motor of this briquetting press is 1kw/15kw/18.5kw/22kw-3phase-380v-50hz.
Technical parameters:
| Model | Capacity | Roller diam | Motor power | Pressure | Roller speed | Briquette size |
| LT-290 | 1.5-2 t/h | 290 mm | 5.5 kw | 40 | 15-17 r/min | 10-80 mm |
| LT-360 | 2.5-4 t/h | 360 mm | 7.5 kw | 60 | 15-17 r/min | 10-80 mm |
| LT-450 | 4-5 t/h | 450 mm | 15 kw | 60 | 15-17 r/min | 10-80 mm |
| LT-500 | 6-8 t/h | 500 mm | 22 kw | 60 | 15 r/min | 10-80 mm |
| LT-650 | 10-15 t/h | 650 mm | 30 kw | 80 | 15 r/min | 10-80 mm |
| LT-850 | 25-35t/h | 850 mm | 37-45 kw | 100 | 13 r/min | 10-80 mm |
| LT-1000 | 35-40 | 1000 mm | 75-90 kw | 120 | 12 r/min | 10-80 mm |
The Five Conditions of the Briquetting Machine:
Before investing briquetting and purchasing wood chip briquetting press, there are five essential conditions you should get prepared.
Sufficient Biomass Raw Materials
Sawdust, rice husks, seed shells, walnut shell, twigs, bark, sediment, vinegar residue, furfural residue, wood chips and various crop stalks are all appropriate materials for briquetting production. Two requirements for raw materials: One is size requirement (particle size less than 1cm) and the other is moisture content requirement (below 12%).
Appropriate Workshop
The size of the workshop is suggested to be larger than 50 square meters and the height cannot be less than 4m. Besides, ensure the workshop can supply three-phase current.
Required Ancillary Equipment
If the raw material is not in particles, four kinds of ancillary equipment are needed: crusher machine, dryer machine, briquetting press and packing machine If the raw material is less than 1cm particles, three kinds of ancillary equipment are required: biomass briquetting press, dryer, packing machine. Buy a carbonization furnace if you want to make charcoal.
Biomass Briquetting Plans
You should make a feasible biomass briquetting plans depending on your specific situation and needs in advance. The devices are not working individually. The whole briquetting process runs as a production line. So a beforehand plan is needed to make your business efficient. Here is an example: one Pipeline type dryer is affordable for two briquetting presses. A 900 * 10000mm tumble dryer can bear five briquetting presses.
Technical Support
Experience and technical support is crucial for a profitable briquetting business. Buying from (a reliable briquette machine manufacturer & supplier) and we will offer technical guidance on factory setting up, briquetting process and tracking service to ensure your business go into operation.
Advantage and features of the machine:
1. High profit and low cost in raw material
2. Increase the net calorific value per unit volume after briquetting
3. Energy saving, friendly-environment, Low-consumption
4. No chemical additives, no smell, no smoke
5. Easy to transport and store as densities product
The production line of the machine
The machines for production line will be loaded in the 20GP, 40GP or 40HQ container to deliver.
The single of less machines will be packed in wooden case and delivered by LCL.
1. Pre-sales service:
1). sales person, project manager, technology engineer, accountant staff.
2). pofessional responding team: would be very fastly and exactly to send you offer.
3). choose suitable machines and make producing plan according to the raw materials, final shapes and output capacity.
4). offer reasonbal price to meet your budget.
5). invite customers to our factory, demostrate the machines, let you know how the machine work, and compare the quality with other suppliers.
6). producing super and solid quality of machines.
7). arrange shipping and fastly delivery.
8). standard export package or as your requirements.
2. After-sales service:
1). assistance to build factory.
2). repairing and maintain if any problems occur in the warranty.
3). help for installation or clerk training, if necessary, dispatch technicians to your country to install the machines.
4). supply spare and wearing parts of our machines.
5). any feedback of our briquette machine for carbon black can be told us, and we will try our best to support you.
6). technology knowlogy shares with you.
7). help for any other machine that we haven't.
Through 30 years of development and technology innovation, our Lantian Mechanical Plant has been developped to a professional manufacturer set design, manufacture, after-sale service as a whole. In order to meet the different requirements of our customers, we designed and researched many types of charcoal process machines, include charcoal & coal briquette machine, shisha & hookah charcoal tablet machines, charcoal & coal extruder machines, and biomass charcoal briquette machines, etc.
Besides, we have also got the CE, ISO, SGS, etc, several patents, and for many years, our machines have been sold home and abroad, and are highly praised by our customers, especially the foreign customers such as Indonesia, Saudi Arabia, Malaysia, India, South Africa, Canada, Australia, Russia, Spain, Greece, Pakiswait, Turkey, Egypt, Sudan, Uzbekistan, Philippines, and other countries.
