Over 20 years experience ball press coal pellet briquette making machine
Our Advantages:
1. Professional manufacturer /Over 20 years experience
2. Whole auto production line
3. Quality with CE ISO 9001 control
4. Full experience for the export,best service after shipment with email
1.The coal pellet ball press machine has two rollers to press fine powder into various shpes.Ball shape/oval shape/egg shape/pillow shape/square shape etc.
2.Raw materials of coal ball press machine can be coal powder,metal powder,carbon
black coal powder,gypsum powder,refractory powder,fertilizer powder, limestone powder etc.
3. Final briquette size of ball press machine will be10-60mm.Which can be customized.
Double roller high pressure coal ball press machine :
Features of lignite coal ball press machine
1.High briquette ratio and high density,energy saving
2.Professional Ball briquette machine manufacturer
3.Advanced briquette technology
4.Environment friendly briquette machine
5.Shape of briquette could be designed according to the customer requirements
6.High pressures briquette machine
Working principle of coal ball press machine
The pressure throughout a closed system is constant. One part of the system is a piston acting as a pump, with modest mechanical force acting on a small cross sectional area; the other part is a piston with a larger area which generates a correspondingly large mechanical force. Only small diameter tubing (which more easily resists pressure) is needed if the pump is separated from the press cylinder. When the pressure on the press cylinder is released (the fluid returning to a reservoir), the force created in the press is reduced to a low value (which depends on the friction of the cylinder's seals.
Technical parameter of lignite coal ball press machine
Type | Roll diameter(mm) | Capacity(t/h) | Power(kw) |
ZKBM290 | 290 | 1-3 | 5.5 |
ZKBM360 | 360 | 4-6 | 11-15 |
ZKBM430 | 430 | 6-8 | 18.5 |
ZKBM500 | 500 | 7-9 | 18.5-55 |
ZKBM500H | 500 | 7-9 | 20.7-57.2 |
ZKBM650 | 650 | 10-15 | 37-45 |
ZKBM650H | 650 | 10-15 | 39.2-47.2 |
ZKBM750 | 750 | 15-20 | 75-110 |
ZKBM750H | 750 | 15-20 | 78-113 |
ZKBM850 | 850 | 20-25 | 90-110 |
ZKBM850H | 850 | 20-25 | 93-113 |
ZKBM1000 | 1000 | 25-30 | 90-132 |
ZKBM1000H | 1000 | 25-30 | 93-135 |
Remarks: Based on different materials, briquettes size, capacity, the technical parameter is adjustable. | |||
