Ball mill is a type of grinder used to grind materials into extremely fine powder for use in mineral dressing processes, paints, pyrotechnics, ceramics and selective laser sintering.
Applications of Small ball mill
Ball mill is a key equipment for regrinding, it is widely used for the cement, the silicate product, new type building material, fire-proof material, chemical fertilizer, black and non-ferrous metal, glass, ceramics and etc.
The ball mill can grind ore or other materials that can be grinded either by wet process or by dry process.
Features of ball mill
1. This type of ball mill is a kind of traditional ball mill, with rolling bearings (Babbit metal bearing bushing seat)
2. Simple structure, and split installation.
3. It is easy to lift it while installing and maintaining.
4. Its feeders are classified into two types: combined feeder and cylinder feeder.
Working principle of ball mill
1. This ball mill is horizontal type and tubular running device, has two warehouses.
2. This machine is grid type and its outside runs along gear.
3. The material enters spirally and evenly the first warehouse of the milling machine along the input material hollow axis by input material device.
Technical Specifications of ball mill
Model | Rotary Speed (r/min) | The feeding size (mm) | The final Size (mm) | Capacity(t/h) | Main Motor (kw) | Weight (t) |
900×1800 | 38 | ≤ 20 | 0.075-0.89 | 0.65-2 | 18.9 | 3.6 |
900×3000 | 38 | ≤ 20 | 0.075-0.89 | 1.1-4.8 | 22 | 4.6 |
1200×2400 | 32 | ≤ 25 | 0.075-0.6 | 1.5-4.8 | 45 | 12.5 |
1200×2800 | 35 | ≤ 25 | 0.074-0.4 | 1.2-3.7 | 30 | 11.5 |
1200×3000 | 32 | ≤ 25 | 0.074-0.4 | 1.6-5 | 45 | 12.8 |
1200×4500 | 32 | ≤ 25 | 0.074-0.4 | 1.6-5.8 | 55 | 13.8 |
1500×3000 | 27 | ≤ 25 | 0.074-0.4 | 2-5 | 75 | 17 |
1500×4500 | 27 | ≤ 25 | 0.074-0.4 | 3-6 | 90 | 21 |
1500×5700 | 27 | ≤ 25 | 0.074-0.4 | 3.5-6 | 110 | 24.7 |
1830×3000 | 24 | ≤ 25 | 0.074-0.4 | 4-10 | 180 | 28 |
1830×6400 | 24 | ≤ 25 | 0.074-0.4 | 6.5-15 | 210 | 34 |
1830×7000 | 24 | ≤ 25 | 0.074-0.4 | 7.5-17 | 245 | 36 |
2200×5500 | 21 | ≤ 25 | 0.074-0.4 | 10-22 | 370 | 48.5 |
2200×6500 | 21 | ≤ 25 | 0.074-0.4 | 14-26 | 380 | 52.8 |
2200×7000 | 21 | ≤ 25 | 0.074-0.4 | 8-36 | 380 | 50 |
2200×7500 | 21 | ≤ 25 | 0.074-0.4 | 16-29 | 475 | 56 |
2100×2700 | 24 | ≤ 20 | 0.074-0.4 | 3.5-25 | 150 | 33 |
2100×3500 | 24 | ≤ 25 | 0.074-0.4 | 4.5-33 | 180 | 37 |
Service and Parts
Hongke Heavy Industry has always delivered the right equipment at the right price.
Hongke Financial Services offer a variety of tailored financing solutions and worldwide shipping arrangements for our clients.
Please email us with your specific requirements so that we may suggest the most viable options for transporting your goods.
Hongke Heavy Industry will train your operators; provide follow-up visits to review the equipment use, and advice on optimal utilization of wear parts.
1. The capacity of the ball mill?
2. The out size of the raw material?
3. What product you use to?
Welcome to your inquiry!
