LPC5-15S Vehicular Hydraulic Pump Wet Shotcrete Machine Concrete Sprayer

US$ 1,000 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

Max. Conveying Distance:

180m

Max Aggregate Size:

25mm

Zhengzhou Lead Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Qingdao or Tianjin or Ningbo or Guangzhou or other

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Max. Conveying Distance 180m

Max Aggregate Size 25mm

Hose Inner Diameter 57 mm

Air Consumption 9-20m3/min

Place of Origin Henan, China

Brand Name LEC

Model Number LPC5-15S

Voltage 380v

Power(W) 18500

Dimension(L*W*H) 5250*1950*2110mm

Weight 3800

Certification ISO CE

Warranty a year

After-sales Service Provided Engineers available to service machinery overseas

LPC5-15S vehicular hydraulic pump wet shotcrete machine concrete sprayer

Product Description

LPC5-15S vehicular hydraulic pump wet shotcrete machine concrete sprayer description:

It can be used for conveying and spraying of plain concrete, fiber concrete.

Features:

Running system. It moves easily from different construction sites without additional traction thus save time.
Pipelines fixed on the vehicle thus save labor and time from connecting and disconnecting pipelines before and after the project.
Integrated machine makes it easy to control and make the site more standardized and orderly.
Compared with common wet shotcrete machine on same condition, the operation cycle of this machines save more than 2 hours. It saves labor and strength.

Technical data

Technical data:

Parameter		unit	LPC5-15S
Pump system	Rated output	m³/h	5-15
	Rated pressure	MPa	4
	Max. Rated vertical distance	m	50
	Max. Rated horizontal distance	m	180
	Distributing valve form		S tube valve
	Max. aggregate size	mm	25
	Slump	cm	12-23
	Air consumption	m³/min	9-20
	System air pressure	MPa	0.7
	Working air pressure	Mpa	0.4-0.6
	Rebound rate	%	less than 15
	Dust density (near machine)	mg/m³	less than 10
	Conveying cylinder ID *stroke	mm	dia.160*800
	Pump motor power	kw	18.5
	Dosing pump motor power	kw	0.55
	Vibrator motor power	kw	0.25
	Cooling fan motor power	kw	0.12
	Voltage/frequency	V/Hz	380/50
	Oil tank volume	L	128
	Charging height	mm	1400
Running system	Running diesel power	kw	20
	Max. running speed	km/h	25
	Wheel track	mm	1500
	Wheel base	mm	2600
	Min. turning radius	m	4.3
	Max. gradeability	%	30
	Min. ground clearance	mm	130
Complete machine	Dimension	mm	525019502110
Complete machine	Weight	kg	3800
