Stainless Steel Duplex Bag Filter Housing

Stainless Steel Duplex Bag Filter Housing thumbnail-1
Stainless Steel Duplex Bag Filter Housing photo-1
US$ 100 - 1,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Jhenten
Model Number:
ZTDS-2P2S
Contact Supplier Request Quote Chat Now
Wenzhou Jhen Ten Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NingBo or ShangHai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Jhenten
Model Number ZTDS-2P2S

Duplex bag filter housing

Product Description

Duplex bag filter housing were consisted of two Top Flow bag filter housings fitted together at the inlet and outlet

by either a butterfly or ball valve assembly.The valves were connected together by a retun handle so as to operate

easily from one bag houisng to to other bag filter housing.The filtration process can flow continously during bag chang-out.

Technical specification

1.Material:SS304 or SS316L

2.Design vessel pressure :0.6-1.0Mpa

3.Operate temperature:-20-130°C

4.Filtering accuracy: 0.1-200um

5.Filter Bag type:1#Bay,2#Bag,3#Bag,4#Bag

6.Flow Type:Side Entry,Top Entry,S-Multi,B-Multi Bag Filter

7.Connection vessel:GB,ANSI,JIS,and other flange

8.Inlet/Out Dimension: 1",1.5",2",2.5",3",3.5",4"

9.Surface Finish: Mirror Polish,Electrical Polish, Acid Washing,Matt Polish,echanical

   Polishing ,Ra≤0.5μm

10.Usage:widely used in Food & Beverage,Wine Industry,Medicine, Chemical Industry,

    Electronic Industry and So On.

Main Technical Parameters

               Modell

Specification

ZT

1-1

ZT

1-2

ZT

1-3

ZT

1-4

ZT

3-2

ZT

 4-2

ZT

5-2

ZT  6-2

ZT

8-2

ZT

10-2

ZTL 12-2

ZT

15-2

ZT

21-2

Bag Quantity (pcs)

1

1

1

1

3

4

5

6

8

10

12

15

21

Filter Area (m2)

0.5

0.5

0.5

0.5

1.5

2

2.5

3

4

5

6

7.5

10.5

Max Flow Rate (T/H)

15

30

3

5

90

120

150

180

240

300

360

450

630

Operationg Date (Mpa)

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

0.1-0.8

Max Temperture (°C)

120

120

120

120

120

120

120

120

120

120

120

120

120



Duplex bag filter housings

Stainless Steel Duplex Bag Filter Housing
