Retort Sterilizer Autoclave

Name: Retort Sterilizer Autoclave
Brand: wanyuan, wanyuan
SKU: 141367170
Availability: InStock

US$ 6,800 - 15,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

wanyuan, wanyuan

Wenzhou Longwan Wan Yuan Food Machinery Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai or ningbo port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Zhejiang, China

Brand Name wanyuan, wanyuan

Model Number GT7CW720...

Usage Canned Food

Type Autoclave

Certification CE

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

retort pouch sterilizer for meat and vacuum boiling package

horizontal steam sterilizer autoclave

wanyuan Brand autoclave retort pouch sterilizer for meat and vacuum boiling package
1.The GT7C sreies horizontal sterilizer is a barrel sterilizeration equipment using the compressing air to do the counter-pressure ,the locking nanhead,using the self-locking,is convenient to open and start.

2.The horizontal sterilizer body:including the body,safely interlocking equipment,the cover,the swivel,the track,the sealing,the idler wheel,the locking block,the steam nozzel.the cooling water pipe,the gate valve,and so on.

MODEL	GT7CW 720	GT7CW 1200	GT7CW 2000	GT7CW2400
MODEL	GT7CW 720	GT7CW 1200	GT7CW 2000	GT7CW2400
produce capacity (cans/one time)	720	1200	2000	2400
Tank body size (mm)	900*1500	1100*2000	1200*3000	1200*3500
volume (m3)	1.1	2.2	3.9	4.5
Number of basket(crate)	2	3	4	5
maximum temperature (⁰C)	143⁰C
working temperature (⁰C)	≤138⁰C
maximum pressure (Mpa)	0.3MPa
working pressure (Mpa)	≤0.25Mpa
safety valve Kai-hop pressure (Mpa)	0.27Mpa
working medium	Food, Water, steam, compressed air
main pressure parts of material	SUS304/Q235-B
Water once sterilization (m3)	≈3	≈4	≈6	≈6.5
weight of equipment(kg)	700	982	1302	1391
External dimensions L×W×H (mm)	2000×1450X1232	2520×1600×1440	3550×1750×1550	4050×1750X1550
