6T/H two stage reverse osmosis systm plant,drinking water treatment equipment
- 30 Set / Sets per Month
- Ningbo port
- T/T Credit Card
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | DF | Model Number: | Reverse Osmosis-6000 |
Product Description
1.Reverse osmosis water treatment plant output water quality
resistivity:≥0.5MΩ.CM conductivity:≤2μS
ammonia≤0.3μg/ml
nitrate≤0.06μg/ml
heavy metal≤0.5μg/ml
2.Reverse osmosis water treatment plant detailed specification
With the report of raw water and the different requirements in different field, we can design a appropriate reverse osmosis water treatment plant for you
Parameters | ||
Product | Two stage Reverse Osmosis water treatment machine | |
Pure Water Production Capacity | 6000 litre per hour(25°C) | |
Input water quality | TDS≤2000PPM(SDI≤5, 2≤PH≥11, NTU≤1) | |
Systematic Salt Rejection Rate | ≥98% | |
Recovery Rate(pure water : inlet water) | 50~75% | |
Recommended Working Temp. | 5~35°C | |
Input Power(standard) | AC380V / 50Hz | |
Pre-treatment | ||
Quartz Sand Filter(Flux: 6M3/H) | Φ900×1850mm(t=2.0mm) SUS304 stainless tank with 1200KG quartz sand Or optional fiber glass tank | |
Active Carbon Filter(Flux: 6M3/H) | Φ900×1850mm(t=2.0mm) SUS304 stainless tank with 350KG activated carbon Or optional fiber glass tank | |
Micron (PP Sediment) Filter | SUS304 stainless steel tank with 40inch PP filter×7PCS | |
Booster Pump | China Nanfang CHL8-30 pump×1PC | |
Multi-stage Pump for first stage RO | China Nanfang CDLS8-160 pump×1PC | |
Multi-stage Pump for second stage RO | China Nanfang CDL4-220 pump×1PC | |
Reverse Osmosis System | ||
Membrane for first stage RO | U.S. HYDRANAUTIC ESPA-8040 membrane × 7PCS Optional VONFRON membrane and DOW | |
Membrane for second stage RO | U.S. HYDRANAUTIC ESPA-8040 membrane × 5PCS Optional VONFRON membrane and DOW | |
Accessories | ||
Piping | SS304 connection | |
Touch-screen PLC control panel | America EMERSON PLC with colorful touch-screen operation | |
Others | Flow metre, TDS metre, pressure metre, electromagnetic valve, etc. | |
OPTIONAL | ||
Chemical dosing System for PH adjustment, anti-scaling, etc. | U.S. Pulsafeeder Xo60 Automatic Dosing valve with 50L tank | |
UV sterilizer | IP67 waterproof grade UV-40W UV sterilizing(up to 5000hour lamp lifespan) Or U.S. Hanovia lamp(up to 9000hours lamp lifespan) | |
Built-in chemical membrane washing device for RO system | For regular membrane cleanning so as to renew and improve the membrane performance |
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
