Reverse osmosis with two stage pure water filter
With the report of raw water and the different requirements in different field, we can make a appropriate design for you.
1) Adopts imported RO membrane from America, which can remove 99.7% inorganic salt, heavy metal ion and completely get rid of colloid, microbiology organic materials, germ, protozoa, pathogens, bacteria, inorganic chemical and so on.
2) No need to add any chemicals, stable pure water quality, and no pollution drained, low produce cost.
3) Equipped with pretreatment system, such as active carbon absorption filter and PP sediment filter.
4) 304 stainless steel rack and pipe accessories connection.
5) Equipped with auto pressure protection system and on -line monitor.
6) Automatically and manually wash RO membrane. Also the design of washing the RO membrane is by chemical solution (citric acid or sodium hydroxide optional)
7) The lifespan of the whole system is long, operation simple, the applicability is strong.
Detailed specification
Model | FW-20m³ |
Purified Water Production Capacity | 20m³per hour (temperature=25°C) |
Input Power | AC380V / 50Hz |
Quartz Sand Filter | FRP tank×1PC: Φ1500×h2400mm with 2,900KG quartz sand Optional: SUS304 tank |
Active Carbon Filter | FRP tank×1PC: Φ1500×h2400mm with 950KG quartz sand Optional: SUS304 tank |
Micron (PP Sediment) Filter | SUS304 tank (including 40inch PP filter ×19PCS) |
UV Sterilizer(Optional) | KCF-UV240W UV sterilizer adopting America Hanovia lamp |
Chemical Dosing System | Germany RDOUS Dosing valve with 80L tank × 1PC |
Booster Pump | China Nanfang pump |
Multi-stage Pump | China Nanfang CDL32-90 |
RO Membrane System | U.S. Hydranautics ESPA-8040 high productivity RO membrane×20PCS Optional: U.S. DOW FILMTEC Blackish Series BW30-400 membrane×20PCS |
RO Membranes Shell | FRP 8040-2 membrane shell×10PCS /optional SUS304 membrane shell |
Packaging | In wooden case |
Accessories | Including valve, piping and electrical systems |
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
