Material
Stainless steel 304,316,304L
Specifications
1.easy to operate;
2.long life span;
3.advanced technology ;
4.Beautiful appearance;
Security filter ( Cartridge Filters)
The security filter is most commonly used for treat water. The whole system adopts one set of stainless filter.
There are 12 pieces of polypropylene in every 5μ filter cartridges, filtering the vast majority of particles in the
water,which eases the load of RO membrane. This process of filtration benefits to the filter cartridge and prolongs
its lifetime in the system. This apparatus contains filtration component and stainless support layers. The support
layer is made of stainless steel 304, with the advantages of compact structure, beautiful shape, high flux, good
filtration accuracy and etc.
Technical parameters:
1.Design pressure: more than 0.6Mpa
2.Work pressure: 0.1-0.4MPa
3.Design temperature: normal temperature
4.Sealing material: butyl rubber, silicone, fluorine rubber standard, standard configuration is silica gel seal
5.Interface form: threaded, bar clasp, GB standard flange
6.Applicable filter: flat crush type PP great filter / 222 socket filter
7.Surface treatment: mirror polishing, electrolytic polishing,sandblast external surface
8.Filtration precision: 1um - 100um
9.Material: SUS304, SUS316, SUS316L
Common specifications:
model | content(T/H) | inlet/outlet | Filter number | full hight | pattern |
Φ195*250 | 1-1.2 | 1″ | 3-5 | 430 | bar clasp |
Φ195*500 | 1.5-2.5 | 1″ | 3-5 | 680 | bar clasp |
Φ195*750 | 3-3.5 | 1.5″ | 3-5 | 960 | bar clasp |
Φ195*1000 | 4-5 | 1.5″ | 3-5 | 1170 | bar clasp |
Φ230*250 | 1-2 | 1″ | 5-7 | 430 | bar clasp |
Φ230*500 | 2-3 | 1.5″ | 5-7 | 680 | bar clasp |
Φ230*750 | 5-7 | 2″ | 5-7 | 960 | bar clasp |
Φ230*1000 | 8-10 | 2″ | 5-7 | 1220 | bar clasp |
Φ230*1000 | 8-10 | 2″ | 5-7 | 1235 | flange |
Φ273*750 | 10-12 | 2″ | 7-9 | 1010 | flange |
Φ273*1000 | 10-14 | 2″ | 7-9 | 1270 | flange |
Φ300*750 | 10-14 | 2″ | 10 | 1020 | flange |
Φ300*1000 | 12-16 | 2″ | 10 | 1280 | flange |
Φ350*1000 | 18-22 | 2.5″ | 12-15 | 1295 | flange |
Φ400*1000 | 20-30 | 2.5″ | 18-20 | 1380 | flange |
Φ500*1000 | 30-40 | DN80 | 30 | 1410 | flange
|
Our Service:
1. Sample service
Sample service is available for our company. And sample time is about 5- 7 days.
2. Customized service
Customized service is also available for us. We can customize products according to your requirements.
3. After-sales service
Our after-sales service start immediately after signing the contract.
1. No matter FOB or CIF the price term is we would try our best to find a lowest freight cost for customers' reference.
2. The third-party inspection always gets real and true data from us and we will send production photos to customers if there is no inspection.
3. Do our best to help customer arrange the shipment and customs clearance.
4. Installation, maintenance and repair instructions with full information.
5.3-15 years warranty depending on different finish and application
6. Accept Changing or Refunding if the products cannot be installed rightly.
Package:
It is inside with plastic film and outside wraped with waterproof paper, pallet package or according to customer's requirements.
