Vacuum Emulsifying Blender
Features :
1.The whole device including emulsifying mixer boiler , oil boiler, water boiler and vacuum system, hydraulic system, electric control system, and working platform.
2.Adopt 304 and 316 stainless steel
3.Polishing and welding meet customer's request and sanitary standard .
4.Working capacity : 20-2000L
Advantage:
- All contact parts are made of SUS316L stainless steel material.
- Mirror polish of the internal layer is 300MESH (sanitary class). Thickness of the material: 6mm.
- Material of jacket: SUS 304 stainless steel. Thickness of material: 5mm.
- Between the internal layer and external layer, it can be heated and cooled,with a leading line, can be heated or cooled by steam and cooled water.
- The thermal insulating layer is made of rock wool or polyurethane foaming to keep warm.
- When jacket was heated, the temperature of the external body of the tank is no more than 40°C. The external layer of the tank body is made of SUS304 stainless steel.
- Exterior polished is in 350MESH (sanitary class).
- Thickness of the material: 3mm.
- All the welding seams shall be polished after rubdown, and as to the treatment interface, turned over edge are transition is adopted.
Technical parameters
Model | Effective Capacity | Emulsify | Agitator | Outside Dimension | |||||
KW | r/min | Kw | r/min | Length | Width | Height | |||
ZRJ-20 | 20 | 2.2 | 0-3500 | 0.37 | 0-40 | 1800 | 1600 | 1850 | |
ZRJ-50 | 50 | 3 | 0-3500 | 0.75 | 0-40 | 2700 | 2000 | 2015 | |
ZRJ-100 | 100 | 3 | 0-3500 | 1.5 | 0-40 | 2920 | 2120 | 2200 | |
ZRJ-150 | 150 | 4 | 0-3500 | 1.5 | 0-40 | 3110 | 2120 | 2200 | |
ZRJ-200 | 200 | 5.5 | 0-3500 | 1.5 | 0-40 | 3150 | 2200 | 2200 | |
ZRJ-350 | 350 | 7.5 | 0-3500 | 2.2 | 0-40 | 3650 | 2650 | 2550 | |
ZRJ-500 | 500 | 7.5 | 0-3500 | 2.2 | 0-40 | 3970 | 2800 | 2700 | |
ZRJ-750 | 750 | 11 | 0-3500 | 4 | 0-40 | 3780 | 3200 | 3050 | |
ZRJ-100 | 1000 | 15 | 0-3500 | 4 | 0-40 | 3900 | 3400 | 3150 | |
ZRJ-1500 | 1500 | 18.5 | 0-3500 | 7.5 | 0-40 | 4000 | 4100 | 3750 | |
ZRJ-2000 | 2000 | 22 | 0-3500 | 7.5 | 0-40 | 4850 | 4200 | 3600 | |
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
