Home > Products > New Products > In the sale of magnetic separation equipment
In the sale of magnetic separation equipment
- 500 Set / Sets per Month
- Qingdao Port
- T/T
Product Details
Condition: | New | Type: | Other, Other, Magnetic Separator | Production Capacity: | 98% |
Place of Origin: | Shandong, China | Brand Name: | SDqz | Model Number: | XJK |
Voltage: | 380V | Power(W): | 7.5kw | Dimension(L*W*H): | 7000*2000*3000 Mm |
Weight: | 750kg | Certification: | ISO9001:2008 | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
according to the contract
Product Description
Magnetic Separation
Company profile
Shandong Hengchuan Ore Machinery Co. , Ltd, established in 2002, is leading ore machinery in china. Company covers area of 20000 square meters.
Our main products :Placer Gold Mining Machine ,Magnetic Separator ,Sand Mining and Washing Machine, Mining Dredgers ,Sand Barges, Particular Vessels, etc. They have been sold not in domestic market, but export to more than thirty foreign countries, like Philippines, Malaysia, North Korea , Mongolia, Cameroon, South Africa, Ghana, Brazil, etc.
Strong Magnetic Force Separator
Short Introduction
1 Strong magnetic separator is designed with advanced technology . The magnetic force can get 1000-22000GS
2 Discharging usually by hairbrush and rubber belt
3 This machine applys to Manganese Mine , Hematite Mine , Limonte Mine , Quartz Mine ,kaolin Mine , Potassium Feldspar ,etc.
4 Have exported to lran , korea , Indonesia and many other countries .
Discharge by hairbrush
Short Introduction
Yype | Capacity T/h | Power | Magnetic strength GS | Magnetic separator type mm |
HCQ-100 | 1-3 | 1-3 | 12000-14500 | 100*1000 |
HCQ-150 | 3-5 | 3-5.5 | 12000-14500 | 150*1200 |
HCQ-220 | 5-10 | 5.5-7.5 | 12000-14500 | 220*1500 |
HCQ-380 | 10-20 | 5.5-11 | 12000-14500 | 380*2000 |
Discharge by rubber belt
MAgnetic Separator plant Short Introduction
1 Dry magnetic separator is used to separate magnetic sand sized smaller than 10mm . It can lower about lower about 50% of power consumption of Ball Mill .
2 There are many models for choice , like Vertical type , Horizontal type , Single cylinder , Double cylinder and Multiple cylinder , etc .
3 If water source available , can adopt water separation machine , like CTS , CTB type magnetic separator .
4 Magnetic force is from 3800-4500GS . Capacity is from 100-200tons per hour .
5 According to the working condition , can adopt Jaw crusher , Hammer crusher or Roller crusher to crush the big materials .
Double cyclinder Vertical Separator
Short Introduction
Type | Capacity T/h | Power Kw | Magnetic Strength Gs | Magnetic separator type mm |
HCG-50 | 50 | 10-20 | 3500-4500 | 750*1800 |
HCG-100 | 100 | 15-30 | 3500-4500 | 900*2600 |
HCG-150 | 150 | 25-50 | 3500-4500 | 900*3000/1050*2600 |
HCG-200 | 200 | 30-80 | 3500-4500 | 1050*3000/1200*2800 |
Plant with Crushers main technical parameters
Type | Capacity T/h | Power Kw | Magnetic Strength Gs | Magnetic separator type mm |
HCG-50 | 50 | 40-60 | 3500-4500 | 750*1800 |
HCG-100 | 100 | 50-80 | 3500-4500 | 900*2600 |
HCG-150 | 150 | 60-100 | 3500-4500 | 900*3000/1050*2600 |
HCG-200 | 200 | 70-120 | 3500-4500 | 1050*3000/1200*2800 |
Company qualification
Contact Us
Name | Andy |
Website | www.hcchina.en.china.cn |
Company Name | Shandong Hengchuan Ore Machinery Co.;Ltd |
Address | Mihe Industrial zone,Qingzhou City,Shandong province |
Company Profile
Qingzhou Hengchuan Ore Machinery Co.,ltd,was established in 2002,a leading ore machinery manufacturer in China,covering an area of 20000 square meters,have 6 engineers,20 technicians and 100 workers.
Our main products:Gold Mining Machinery,Magnetic separators and all kinds of mining dredger etc.Our main market is domestic,Africa and Southeast Asia,such as Cameroon,Ghana,Mali,Zimbabwe,Malaysia,Indonesia and Philippines etc.
Cutter suction dredger is widely used in dredging engineering.The rotating cutting head in the front of the suction pipe can stir slurry,then dredging pump suck the slurry through the suction pipe,then through the discharge pipe to the mud yards.Dredging, transportation and discharge is a whole series work.So the cutter suction dredger is an efficient and economic dredger.We start to manufacture the cutter suction dredger from 2005,gradually accumulated rich experience in this field.
Development History:
A).Established Magnet Research Institute in 2004,successfully developed the high gradient magnetic separator to 12000-22000GS.
B).Cooperated with Shandong Gold Group and doubled the sales scale.
C).Developed STL-120 gold centrifugal concentrator in 2008.
D).Mature dredger products in 2009.
E).Developed successfylly knelson smiliar type automatic discharge type gold centrifual concentrtor and produced them in large quantity for sellling.
F).Established Shandong Hengchuan International Trade Co.,Ltd in 2015.
Enterprise Spirit -eternal integrity
Enterprise Purpose-to consistently exceed customers' expectations
Core Values-innovation and leading the future
Service Concept- to create value for customers
Development Concept - Quality is life; innovation is the driving force
Corporate Vision- the world leading supplier of magnetic separation equipment
Contact Us
- Qingzhou Hengchuan Ore Machinery Co., Ltd.
- Contact nameKatherine Lee
- Phone86-536-2136165
- AddressConstruction Area, East To Donghong Road, Yangjia Village, Mihe Town, Qingzhou
